MB851 connectors: P1 pins

Table 7.
10/37
www.BDTIC.com/ST
MB851 connectors: P1 pins
Pin number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
Doc ID 16999 Rev 5
UM0894
GPIO function
+VBRD
PC5
nRST
PA7
PB3
PB4
PA0
PA1
PA2
PA4
PA3
PA6
PA5
GND
PB1
PB2
JTCK
PC2
PC3
PC4
GND
GND
PB0
PC1
PC0
PB7
PB6
PB5
