EventLITE 4/10 Q4 Set 6x
Channel 5 – Blue Dimmer intensity
0–255 Gradual adjustment Blue, from dark to brightest
Channel 6 – White Dimmer intensity
0–255 Gradual adjustment White, from dark to brightest

9 Channels

Channel 1 – Master Dimmer intensity
0–255 Dimmer intensity, from dark to brightest
Channel 2 – Linear strobe
0–10 Closed
11–255 Strobe flash frequency, from low to high frequency (0–15 Hz)
Channel 3 – Red Dimmer intensity
0–255 Gradual adjustment Red, from dark to brightest
Channel 4 – Green Dimmer intensity
0–255 Gradual adjustment Green, from dark to brightest
Channel 5 – Blue Dimmer intensity
0–255 Gradual adjustment Blue, from dark to brightest
Channel 6 – White Dimmer intensity
0–255 Gradual adjustment White, from dark to brightest
Channel 7 – Color presets
0–10 No function
11–13 Color 1 (R255, G000, B000, W000)
14–20 Color 2 (R255, G000, B000, W100)
21–27 Color 3 (R255, G000, B000, W200)
28–34 Color 4 (R255, G050, B000, W000)
35–41 Color 5 (R255, G150, B000, W000)
42–48 Color 6 (R255, G255, B000, W000)
49–55 Color 7 (R255, G255, B000, W075)
56–62 Color 8 (R255, G255, B000, W255)
63–69 Color 9 (R000, G255, B000, W150)
70–76 Color 10 (R000, G255, B000, W050)
77–83 Color 11 (R000, G255, B000, W000)
84–90 Color 12 (R000, G255, B050, W000)
91–97 Color 13 (R000, G255, B150, W000)
98–104 Color 14 (R000, G255, B255, W000)
105–111 Color 15 (R000, G255, B255, W075)
112–118 Color 16 (R000, G255, B255, W150)
119–125 Color 17 (R000, G100, B255, W255)
126–132 Color 18 (R000, G000, B255, W100)
133–139 Color 19 (R000, G000, B255, W050)
140–146 Color 20 (R000, G000, B255, W000)
147–153 Color 21 (R075, G000, B255, W000)
154–160 Color 22 (R160, G000, B255, W000)
161–167 Color 23 (R255, G000, B255, W000)
168–174 Color 24 (R255, G000, B175, W000)
175–181 Color 25 (R255, G000, B100, W000)
182–188 Color 26 (R255, G000, B100, W050)
Ordercode: 44061
CH1 must be open
CH1 must be open
CH1 and CH3–6 must be open
CH1 must be open, CH7–8 must be closed
CH1 must be open, CH7–8 must be closed
CH1 must be open, CH7–8 must be closed
CH1 must be open, CH7–8 must be closed
CH8 must be closed
