EventLITE 4/10 Q4 Set 6x

4. DMX Address/DMX Channel Mode

01) Press the button to set the desired DMX starting address. The display will read ADDRESS.
02) Press the and
001–512.
03) Press the button again, to set the desired DMX channel mode. The display will read CHANNEL.
04) Press the and
options:
●

4 channels

● 6 channels
● 9 channels

5. Economy

01) Press the button to set the device's energy-saving mode. The display will read ECONOMY.
02) Press the and
03) If you have chosen ON, the EventLITE will operate at 80 % of its efficiency (economical mode).
04) If you have chosen OFF, the EventLITE will operate at 100 % of its efficiency (normal mode).

DMX Channels

4 Channels
Channel 1 – Red Dimmer intensity
0–255 Gradual adjustment Red, from dark to brightest
Channel 2 – Green Dimmer intensity
0–255 Gradual adjustment Green, from dark to brightest
Channel 3 – Blue Dimmer intensity
0–255 Gradual adjustment Blue, from dark to brightest
Channel 4 – White Dimmer intensity
0–255 Gradual adjustment White, from dark to brightest
6 Channels
Channel 1 – Master Dimmer intensity
0–255 Dimmer intensity, from dark to brightest
Channel 2 – Linear strobe
0–10 Closed
11–255 Strobe flash frequency, from low to high frequency (0–15 Hz)
Channel 3 – Red Dimmer intensity
0–255 Gradual adjustment Red, from dark to brightest
Channel 4 – Green Dimmer intensity
0–255 Gradual adjustment Green, from dark to brightest
Ordercode: 44061
buttons to set the desired DMX address. The adjustment range is between
buttons to set the desired DMX channel mode. Choose one of the 3
buttons to choose ON or OFF.
CH1 and CH3-6 must be open
CH1 must be open
CH1 must be open
33
