IPALMOD | SERVICE MANUAL
4. Main Board Layout:
Please note that the output 5x20 fuses are not mounted by default.

5. Disassembling the main board:

Unscrew all 9 screws and nuts holding the components
to the chassis sides and remove the 4 clips highlighted
in (Fig. 6).
Gently pry the heatsink-mounted components off from
the heatsink by means of a flat head screwdriver. (Fig. 7)
6
DC/DC
CONV
Remove Jumper to Remove Jumper to
enable DSP insert external circuit
(Fig. 6)
(Fig. 7)
