IPALMOD | SERVICE MANUAL
DPC interface board's LED at start-up
Color
Label
RED
PROTECT
RED
LIMIT
GREEN
SIGNAL
GREEN
E.SAVE
YELLOW
TEMP
GREEN
READY
GREEN
ON
GREEN
PRESET
DPC interface board's LED after 3 seconds
Color
Label
RED
PROTECT
RED
LIMIT
GREEN
SIGNAL
GREEN
E.SAVE
YELLOW
TEMP
GREEN
READY
GREEN
ON
GREEN
PRESET
DPC interface board's LED after 30 seconds
Color
Label
RED
PROTECT
RED
LIMIT
GREEN
SIGNAL
GREEN
E.SAVE
YELLOW
TEMP
GREEN
READY
GREEN
ON
GREEN
PRESET
14
Condition
OFF
SOLID ON
SOLID ON
OFF
OFF
SOLID ON
SOLID ON
OFF
Condition
OFF
OFF
OFF
OFF
OFF
SOLID ON
SOLID ON
OFF
Condition
OFF
OFF
OFF
SOLID ON
OFF
SOLID ON
SOLID ON
OFF
