LED indication and Settings

LED indication
LED LED Status
OFF
Green Blinking
Green single flash
RUN
Green flickering
Green ON
OFF
Green ON
L/A IN
Green flickering
OFF
Green ON
L/A OUT
Green flickering
Green ON
PWR
OFF
Green ON
PWR(V)
OFF
*1: Blinking pattern
*2: Single flash pattern
*3: Flickering pattern
INIT
*1
PRE-OPERATIONAL
*2
SAFE-OPERATIONAL
*3
BOOTSTRAP
OPERATIONAL
BUS IN side: No Link, No Activity
BUS IN side: Link, No Activity
*3
BUS IN side: Link, Activity
BUS OUT side:No Link, No Activity
BUS OUT side: Link, No Activity
*3
BUS OUT side: Link, Activity
SI unit operating voltage is supplied
SI unit operating voltage is not supplied
Load voltage for the valve is supplied
Load voltage for the valve is not supplied or
outside tolerance range (19 V or less)
-13-
