Mounting and Installation

■General instructions on installation and maintenance

Connect valve manifold to the SI unit.
●Installation example
n
L
L1
L2
ｎ
L
L1
L2 192 208 224 240 256 272 288 304
The above table shows dimensions as an example for the SY5000 series valve manifold.
Connectable valve manifolds are same as for EX250 series SI unit.
Refer to the EX250 series valve manifold section in the valve catalogue for valve manifold dimension.
1 2 3
120.7 136.7 152.7 168.7 184.7 200.7 216.7
80 96 112 128 144 160 176
9 10 11
232.7 248.7 264.7 280.7 296.7 312.7 328.7 344.7
4 5 6
12 13 14
-9-
n: number of valve stations
7 8
15 16
(mm)
