Havis C-VS-1500-DUR-1 Install Instructions Manual

15” vehicle specific console for 2011 - 2013 dodge durango with oem center shifter
Hide thumbs

Advertisement

Table of Contents

INSTALL INSTRUCTIONS C-VS-1500-DUR-1
2011 - 2013 Dodge Durango with OEM Center Shifter
TOOLS NEEDED:
Phillips Screw Driver
Standard Socket set
Metric Socket set
QTY
1
1
1
1
1
1
1
2
2
1
1
2
6
10
3
4
4
15
9
8
8
1
Read all instructions before installing any Havis, Inc. products.
Use hardware provided with install kit.
15" VEHICLE SPECIFIC CONSOLE for
DESCRIPTION
Main Console Housing
Base mount bracket
Shifter mount platform
Top console Bezel
Shifter cover
Driver side trim panel
Passenger side trim panel
Retaining bracket
10-32 Nylock nut
Cup Holder
Hardware kit
C-HK-211 Hardware Kit includes the following
12 volt socket
1/4 x 1/2" Hex head bolt
1/4 x 3/4" Hex head bolt
1/4 x 1 ¼" Hex head bolt
1/4 x 1/2" Carriage bolt
1/4 serrated nut
1/4 Flat washer
1/4 Lock washer
# 8 x 1/4" Flat head sheet metal screw
# 8 x 3/8" Torx head screw
2" x 2 ½" x 8" foam block
NOTES!
90° Phillips Screw Driver
T-20 Torx Bit
Wire Crimping tool
Wire Cutters
PART #
CM005190
CM005005
CM005006
CM005012
CM005011-1
CM005024
CM005025
CM005270
GSM30015
CM001629
C-HK-211
CM216560
GSM33000
GSM33001
GSM34033
GSM31999
GSM30023
GSM31005
GSM31026
GSM33178
CM86508
CM007533
C-VS-1500-DUR-1_INST_12-12 rev10-15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-VS-1500-DUR-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Havis C-VS-1500-DUR-1

Summary of Contents for Havis C-VS-1500-DUR-1

  • Page 1 # 8 x 1/4” Flat head sheet metal screw GSM33178 # 8 x 3/8” Torx head screw CM86508 2” x 2 ½” x 8” foam block CM007533 NOTES! Read all instructions before installing any Havis, Inc. products. Use hardware provided with install kit. C-VS-1500-DUR-1_INST_12-12 rev10-15...
  • Page 2 C-VS-1500-DUR-1 (Main Housing Assembly) CM005025 Passenger side trim panel CM005011-1 Shifter cover CM001629 CM005024 Cup Holder Driver side cover panel CM005012 Top Console Bezel CM005270 Retaining bracket CM005006 Shifter mount platform (inside console) CM005190 Main Console Housing CM005005 Base mount bracket...
  • Page 3 Carefully slide down (unsnap) Carefully remove retaining clip that O.E.M. console prior to removal chrome trim piece under shifter holds knob onto shifter shaft. knob. (Needle nose pliers work well) Carefully pop out coin tray from console Carefully unclip and remove top Remove shifter knob top panel and save to be reused.
  • Page 4 Remove arm rest and hinge Carefully unclip and remove Note: Some vehicles may have rear assembly. console rear end panel. controls in panel that will require (Phillips screwdriver) removal of electrical connectors. Remove four (4) bolts holding the Carefully unclip and remove Remove rear side screws holding main plastic console housing to console side panels.
  • Page 5 Carefully unclip shift cable mount Remove forward base screws from Remove shifter assembly and unbolt cable end. lower dash and save screws Take note of correct position of .(one each side) cable mount parts. (7 mm socket) Save Hardware O.E.M. console housing removed. Unplug main console harness from Remove OEM plastic base plate lower end of dash.
  • Page 6 Attach # CM005006 front shifter Place shifter assembly into base Attach base bracket to front platform to base bracket with six bracket. Do not bolt in yet. O.E.M. floor mount with O.E.M (6) 1/4 x 1/2 Hex head bolts, lock Carefully reattach shifter cable screws previously removed.
  • Page 7 Loosely attach front passenger side Loosely attach front driver side Loosely attach forward housing console housing to lower dash with console housing to lower dash with sides to base bracket with 1/4” x previously removed O.E.M. screw. previously removed O.E.M. screw. 3/4"...
  • Page 8 Console includes mounting View of console at rear end. New console housing with control provisions for side mounted C-HDM-204 computer mount heads and accessories installed. bracket. View of C-HDM side computer mount. View of completed installation on passenger side. View of completed console and laptop mount in a 2012 Dodge Durango. C-VS-1500-DUR-1_INST_12-12 rev10-15...
