Setup
Connect the
IpalMod Pressure Sensor
the module's DSP Board.
Complete the rest of the connection between the
the module's DSP Board.
Connect the module to the
KT000291
PAY EXTRA ATTENTION WHEN USING THE
KT000291 SERVICE BOARD, ANY IMPROPER AC-
CIDENTAL CONNECTION MAY CAUSE DAMAGES
TO THE AMPLIFIER.
to the CN109 connector on
DPC Board
and
Interface.
