Figure 8. ADL6012-EVALZ, Layer 3
Figure 9. ADL6012-EVALZ, Bottom Layer
NOMINAL
FINISHED
BOARD
THICKNESS
0.062"
±10%
CHARACTERISTIC IMPEDANCE = 50Ω ±10%
ARTWORK LINE WIDTH FOR
IMPEDANCE-CONTROLLED LINES = 0.0135"
Rev. 0 | Page 7 of 9
PRIMARY SILKSCREEN
PRIMARY SOLDER MASK
PRIMARY SIDE (LAYER 1)
8mil ROGERS 4003
GROUND PLANE (LAYER 2)
37OHR
GROUND PLANE (LAYER 3)
8mil ROGERS 4003
GROUND PLANE (LAYER 4)
SECONDARY SOLDER MASK
SECONDARY SILKSCREEN
Figure 10. ADL6012-EVALZ Stack Up
