ADL6012-EVALZ
User Guide
UG-1675
KEYSIGHT MS0S254A
E8257D SIGNAL GENERATOR
AGILENT 1131A
DIFFERENTIAL PROBE
POWER SUPPLY
E3631A 5V
Figure 3.
ADL6012
Envelope Measurement Using Differential Probe
KEYSIGHT MS0S254A
50Ω
50Ω
E8257D SIGNAL GENERATOR
POWER SUPPLY
E3631A 5V
Figure 4. Differential Envelope Output Measurement for AM or Pulsed RF Response
Rev. 0 | Page 5 of 9
