REMOVING THE SEAT COVER

The seat cover consists of five parts which are fixed to the
seat with velcro, press studs or button holes. One you have
released the fasteners, the cover parts can be removed. To
remove the covers, please follow the instructions below:
• Take off the "Linear Side-Impact Protection" System
(L.S.P.) by pushing it upwards to release it from its
anchorage points.
• Undo the press studs on the lower side of the cover for
the adjustable headrest. Then you can remove the cover
upwards.
• Activate the adjustment handle for the headrest and move
this to its highest position.
• Open and loosen all the press buttons on the rear side of
the headrest. Then pull the cover off forwards.
• Pull down the cover on the left and right side panel of the
shoulder rest. Then undo the press studs on the interior of
the shoulder wings in order to be able to entirely remove
the cover.
• Before you can remove the backrest cover from the seat,
undo the associated fastenings its rear side.
• Then thread the elastic bands out on the underside of the
seat area, and withdraw the seat cushion cover forwards.
NOTE! Before removing the separate parts of the seat cover,
please ensure that the cover is already positioned above the
decorative silver parts. To put the covers back on the seat,
proceed as above in reverse order. Make sure that the green
!
belt guide (21) always rests visible above the seat cover.
21 WARNING! The infant car seat must under no
circumstances be used without the cover.
