Cabinet Assembly - Arrow JUDY 101 Owner's Manual

Understanding How the "ARROW-LOC" Cam Fastener Works
Position bolt in
pre-drilled hole and
turn until tight.
Step 1. Place Top (A), Bottom (B), Door (K) and Door
Bin Front Panel (H) on a flat protected surface to
Judy Sewing Machine Cabinet
ARROW TOWARDS
HOLE IN EDGE!
Press cam Into pre-drilled
hole until flush with surface.

Cabinet Assembly

K
H
Insert bolt through pre-drilled
hole in edge of panel.
prevent scratching of parts, thread cam bolts (16
total) into pre-drilled holes (as shown In FIG. 1).
FIG. 1
B
Page 3
180°
To lock, rotate cam
until tight, using
screwdriver.
Cam Bolt x16
A
Assembly Instructions
