- Page 1 J U D Y SEWING MACHINE CABINET OWNER’S MANUAL Where Creativity Meets Color! Assembly Instructions Model Numbers: 101 White IMPORTANT: Please read these instructions before assembling!
- Page 2 CHOKING HAZARD – Small parts. Not for children under 3 years. Please retain this information for future reference. ARROW WARRANTY Congratulations on the purchase of your new JUDY sewing cabinet. Every effort has been taken to ensure your complete satisfaction with this custom designed product. For your convenience, the ready-to-assemble JUDY cabinet is provided in two boxes.
- Page 3 • Your Name, Address, and Phone Number cs@arrowcabinets.com 1-800-533-7347 Ext. 1 Arrow Cabinets P.O. Box 307, Delavan, WI 53115 TO ORDER REPLACEMENT PARTS CALL 1-800-533-7347 Wooden Materials Parts are labeled with capital letters. To reference letters, turn to the Wood Parts List in the back of your manual.
-
Page 4: Hardware Included
Hardware Included Cam 12mm x8 Cam Bolt x16 Set: Magnet with Catch Plate & 3 screws Castor 50mm Castor 50mm Dowel 8x30 x8 Non-Locking x3 Locking x2 #5x5/8” Panhead Screw x2 Screw 10x60mm x4 #5x5/8” Caster Washer x4 Brass Flathead Screw x1 Cover Cap x4 Spaner x1 Screw M4x14 x26... -
Page 5: Cabinet Assembly
Understanding How the “ARROW-LOC” Cam Fastener Works 180° ARROW TOWARDS HOLE IN EDGE! Position bolt in Press cam Into pre-drilled Insert bolt through pre-drilled To lock, rotate cam pre-drilled hole and hole until flush with surface. hole in edge of panel. - Page 6 Step 2. Install Cams (8 total) by pushing a cam After installing the cams, insert the Dowels 8x30 into each hole flush with surface, the arrow (x8) in the both Side panels (C & D) as shown in on the cams should be turned (using a regular FIG.
- Page 7 Step 4. Turn Bottom (B) panel over and install preinstalled threaded seats and placing Caster the Locking caster on right front and Non-locking washer between caster and cabinet bottom. casters in the back and left front using the Tighten with spanner. FIG.
- Page 8 Step 6. In each of the two Door Bin Sides (I) panels, In Door Bin Bottom Panel (J) install Wood dowels install 10 mm cams (x8) with arrow on cam pointing (x6) in the holes on all sides. to hole on outer edge as shown in FIG. 6.
- Page 9 Step 8. Using 2 Screws (M4x14mm) for each door hardware bag (#5 x 5/8 Brass Flathead Screw). hinge attach hinges to raised section of Door (K). Install the Locking caster through caster plate on Attach Door catch plate with screw included in bottom of Door (K).
- Page 10 Step 10. Set Back Panels (E) between panels C holes in side panels into back and tighten 2 screws and D. Insert the Screw 10x60mm (x4) through on each side. Press screw head covers in place. FIG. 11 Screw 10x60mm x4 Cover Cap x4 Step 11.
- Page 11 Step 12. Install the lifter onto side rails following be used to push cord into tab. Push lifter down these steps. until it clicks into first position. When lifter has A. Position lifter guides (white plastic) over rails locking in first position, a small block of wood and gently slide the lifter into position.
- Page 12 Step 14. Attach the Door (K) to Left Side Panel (C) with 3 flush door hinges using the 6 remaining FIG. 15 Screws M4x14mm. Screw M4x14 x6 Step 15. Add door handle using bolts found with Step 16. Slide the preassembled door bin over handle.
- Page 13 Judy Sewing Machine Cabinet Page 11 Assembly Instructions...
- Page 14 Enhance your sewing experience with a custom- Our adjustable height sewing chair is a perfect made insert for your Arrow or Kangaroo cabinet. accessory for any craft and sewing room. The chair’s Inserts are designed to reduce the gap between height is adjustable with easy to use controls and the machine and cabinet opening.
