- 1 Arc Desk Assembly Instructions
- 2 Step 1: Loosely Attach the Legs and the Modesty Panel
- 3 Step 2: Flip the Table over on a Smooth, Clean Surface
- 4 Step 3: Align the Frame Assembly with the Pilot Holes
- 5 Step 4: Go Back and Tighten the Frame Assembly
- 6 Step 5: Tighten the Screw to Secure the Legs
- 7 Step 6: Adjust the Legs to the Desired Height
- Download this manual
Arc Desk Quick Installation Guide
#10 Wood Screw
(Qty. 17)
P/N-70054
Back Panel
(Qty. 1)
Replacement pack 69729 includes:
(4) 70867- Connector Bolt ¼-20X23mm
(4) 70871- Connector Nut ¼-20X17mm
(2) 77813- Allen Wrench 3/16"
(17) 70054- SM Screw #10X3/4
If you have damaged or missing component, please contact customer service
Form# 179837
(Model#: 01350, 01351, 01352, 01353)
3/8" – Dog Nut Screw
(Qty. 4)
P/N-77741
Allen Wrench 3/16"
P/N-77813
Arc Desk Table Top
(Qty. 1)
800-328-1061
www.smithsystem.com
(Qty. 2)
Connector Bolt (Qty. 4 of each)
P/N-70867- Connector Bolt
P/N-70871- Connector Nut
Adjustable Y Legs
(Qty. 2)
02/2013
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SMITH SYSTEM 01350
Summary of Contents for SMITH SYSTEM 01350
- Page 1 Arc Desk Quick Installation Guide (Model#: 01350, 01351, 01352, 01353) Connector Bolt (Qty. 4 of each) #10 Wood Screw 3/8” – Dog Nut Screw P/N-70867- Connector Bolt (Qty. 17) (Qty. 4) P/N-70871- Connector Nut P/N-70054 P/N-77741 Allen Wrench 3/16” (Qty. 2)
- Page 2 Arc Desk Assembly Instructions Step 1: Loosely attach the legs and the modesty panel with (4) Connector Bolts (finger tight) (See Drawing 1A). Step 2: Flip the table over on a smooth, clean surface with the bottom facing up. Step 3: Align the frame assembly with the pilot holes and use (14) Wood Screws to loosely attach to the top (See Drawing 1B) Step 4: Go back and tighten the frame assembly.
