- Page 1 Assembly Instructions Planner Studio Fixed Height Tables If you have damaged or missing components, Please contact customer service at 1-800-328-1061 Form# 179913 08/2018...
- Page 2 Hardware and Components PLANNER STUDIO TOP PLANNER STUDIO SUPPORT CHANNEL QTY. 1 QTY. 1 (2 ON 48” LEG SETS) PACK #17543 PLANNER STUDIO LEG QTY. 2 ALLEN KEY QTY. 1 ¼-20 X 3” BOLT QTY. 6 (12 ON 48” LEG SETS) 4”...
-
Page 3: Special Notes
Special Notes: TOOLS REQUIRED: • Drill w/#2 phillips driver bit, or #2 phillips head screwdriver. • 7/16” socket & ratchet, or 7/16” wrench. • Drill, or impact driver, or adjustable wrench (tables with glides only). • Rubber mallet, or similar (tables with glides only). ... - Page 4 Assembly Instructions 1. Lay top down on a clean smooth surface that will not harm the top finish. Underside of top should be exposed. Top is heavy, team lifting is advised. 2. Position the support channel(s) onto the top, as shown. Do not attach support channel to top yet.
- Page 5 3. Attach the now assembled frame to the wood top using #10 x ¾” wood screws. Hole pattern on underside of top serves as a guide for proper positioning. 4. CASTER / GLIDES INSTALLATION a. CASTERS - Install casters using the caster wrench. Hand tighten until very snug. Form# 179913 08/2018...
- Page 6 4. CASTER/FOOT INSTALLATION (continued…) b. GLIDES - Step 1: Install LEG EXTENSION to leg using SOCKET HEAD CAP SCREW. i. Tighten screw using the supplied STRAIGHT HEX KEY in combination with a drill or wrench as shown. ii. Tighten firmly. GLIDES - Step 2: Carefully tap PLASTIC INSERT in using rubber mallet (or similar).
- Page 7 5. With a partner, team lift table and flip to the upright position. Helpful hint: Lock all casters to prevent unexpected rolling when table legs touch down. …TABLE WITH CASTORS …TABLE WITH GLIDES DONE. Form# 179913 08/2018...
