Technical specifications
Table 2 Technical specifications
Item
Rated input voltage
Rated output voltage
Maximum input current
Maximum output current
Maximum output power
Dimensions (H × W × D)
Ambient
temperature
Power module configuration
Follow these guidelines to configure power modules for the device:
•
Determine the total number of power modules based on the
actual power consumption, the power module slot number, and
power redundancy design.
•
Determine the power module redundancy design based on the
power source conditions.
Operating
temperature
Storage
temperature
Specifications
100 to 240 VAC @ 50 or 60 Hz
240 VDC
16 A
55.6 A
• 1200 W @ 110 VAC
• 2400 W @ 175 to 200 VAC
• 3000 W @ 220 VAC
41 × 100 × 332 mm (1.61 × 3.94
× 13.07 in)
–10°C to +50°C (–14°F to
+122°F)
–40°C to + 70°C (–40°F to
+158°F)
4
