WARNING!
Allow the power module to cool before you remove the power
module.
The following procedure removes the power module above the fan
tray slots.
To remove the power module:
1.
Pressing the latch in the direction towards the handle, pull the
power module part way out of the slot along the guide rails.
2.
As shown in
with one hand and supporting the bottom of the power module
with the other, pull the module slowly along the guide rails out of
the slot.
Figure 7 Removing a power module
3.
Place the power module on an antistatic mat.
Figure
7, grasping the handle of the power module
12
1
2
