Install the Access Point on a Beam
Procedure
1. Attach the beam clip to the main mounting bracket.
Slide the beam clip accessory into the rear hinges on either side of the main mounting bracket and
slightly twist it until the clip locks into place.
Figure 9: Beam clip accessory attached to the main mounting bracket
2. Place the access point onto the main mounting bracket feet and slide it down to lock it in place.
3. Place the beam clip accessory on a beam.
30 ExtremeWireless™ AP310i/e Access Points
Note
Ensure that you leave enough space between the beam clip accessory screw and the
clamp. This helps to tighten the beam clip accessory screw easily.
Install the Access Point
