Drive Shaft coupling
•
Washer
Nut(1)
•
Note:
Use the coupling gear / middle shaft
tool (2) to hold the drive shaft coupling.
Nut Torque 97 Nm or 71 ft lbs
Install the middle drive shaft
Tighten the middle pinion gear nut
•
(1) to 145 Nm or 107 ft lbs
Lock the threads with a drift punch.
•
Engine
4‐48
