Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty
O
'
M
peratOr
s
anual
4x4 Utility Vehicle — Model Series C460
4x2 Utility Vehicle — Model Series C470
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA
Form No. 769-03630
(December 11, 2007)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C460 series and is the answer not in the manual?

Questions and answers

Don
June 7, 2025

How do I open the hood?

0

Subscribe to Our Youtube Channel

Related Manuals for Cub Cadet C460 series

Summary of Contents for Cub Cadet C460 series

  • Page 1 READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY. CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 Printed In USA Form No. 769-03630...

  • Page 2: Table Of Contents

    Choose from the options below: ◊ Visit us on the web at www.cubcadet.com ◊ Locate your nearest Cub Cadet Dealer at (877) 282-8684 ◊ Write us at Cub Cadet LLC • P.O. Box 361131 • Cleveland, OH • 44136-0019...

  • Page 3: Safe Operation Practices

    Important Safe Operation Practices WARNING: This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury.
  • Page 4 This is an off-road utility vehicle and it should not be Never leave vehicle unattended with the key in the operated on public highways. Know and comply with all ignition. Always turn key to the “Stop” position, set the laws and regulations governing the use of off-highway parking brake and remove key.
  • Page 5 Go slow and use extra care when towing a trailer. Allow for Never secure any parts other than Cub Cadet increased braking distance. Load trailer properly. approved accessories on the main frame or attach Do not tow heavy loads on slopes greater than 5° incline.

  • Page 6: Spark Arrestor

    Use extreme care while approaching blind corners, into drinking from them. Properly dispose of the containers doorways, shrubs, trees or other objects that may immediately following the draining of fluids. block your vision of a child who may run into the DO NOT pour oil or other fluids into the ground, down a path of the vehicle.

  • Page 7: Controls & Features

    Controls and Features Figure 4-1 4x4 Switch (4X4 Only) Accelerator Pedal Ignition Switch Adjustable Seat Lever (if equipped) Brake Pedal Shift Lever Differential Lock Lever Cup Holders (if equipped) Parking Brake Lever Seat Belts Warning Light Cluster Fuel Tank Engine Over-Temp Light Choke Knob 12 Volt Power Outlet Read this operator’s manual, safety labels, and operating instructions on the vehicle before operating.

  • Page 8: Accelerator Pedal

    Accelerator Pedal Differential Lock Lever The accelerator pedal is located on the right side of the floor The differential lock lever is located in the center console beneath the dash panel. Depressing the accelerator pedal will between the seats. When engaged, the differential lever locks move the vehicle in the direction selected on the gearshift.

  • Page 9: Seat Belts

    4x4 Switch (4x4 Only) Rear Power Outlet Switch (Optional) The 4x4 switch is located on the right side of the dash panel. If equipped, the rear power outlet switch is located on the left Push in top/bottom of switch to activate or deactivate 4x4 side of the dash panel.

  • Page 10: Operation

    Operation Filling Fuel Tank Stopping Engine Stop vehicle on a level surface and apply parking brake. To stop utility vehicle, release accelerator pedal and depress brake pedal until vehicle comes to a complete Turn the ignition key to the STOP position and remove the stop.
  • Page 11 Engaging 4x4 Electric Lift (Optional) The 4x4 switch is located on the right side of the dash panel. See Park the vehicle safely and turn key to the RUN position. the Controls & Features section. Raise cargo box by pressing and holding top of electric lift To engage, stop or slow vehicle speed and push up on the switch.

  • Page 12: Towing Loads

    Always use approved hitch and hitch point provided for the In the event of an accident, have the OPS carefully utility vehicle. Do not modify the hitch in any way. inspected and, if necessary, replaced by your Cub Cadet dealer. Do not attempt to repair the OPS. Transporting Vehicle IMPORTANT: Never tow the vehicle.

  • Page 13: Maintenance & Adjustment

    Maintenance & Adjustments Engine NOTE: If necessary, you may remove the fill level plug to assist with determining the level to which the transmission Read the Kohler engine operator’s manual for any service or may be filled. See Fig. 6-1. When oil begins coming out of maintenance information pertaining to the engine.

  • Page 14: Tire Pressure

    If damage is noted, contact your Cub Cadet dealer. If an accident has occurred which may have damaged the OPS, have the OPS thoroughly inspected by your Cub Cadet dealer. WARNING: To ensure the structural integrity of the OPS to provide operator protection, do not attempt to straighten or weld the OPS.
  • Page 15 See Fig. 6-4. If excessive wear appears, have ball Remove CVT cover drain plug. See Fig. 6-6. joints or tie rod ends replaced by your local Cub Cadet dealer. Allow water to completely drain out. Reinstall drain plug, and tighten securely.

  • Page 16: Service

    Service Fuses Headlight Bulbs Unlatch and lift hood forward to get access to under the Raise hood to get access to the headlight assembly. dash panel. Turn the bulb/socket assembly approximately a quarter turn counterclockwise to align its tabs with the notches of Remove fuse holder cover.

  • Page 17: Cub Cadet Dealer

    32 to 36 ft. lbs. Replace wheel as described in Wheel section. Drive Belt IMPORTANT: Several components must be removed in order to change the vehicle’s drive belt. See your Cub Cadet Dealer to have your drive belt replaced. 7 — s ectiOn...

  • Page 18: Maintenance Chart

    Maintenance Chart Maintenance Schedule Before Each First 10 Every 50 Every 100 Every 500 Service Hours Hours Hrs. or Yearly Hrs. or 2 Yrs. Dates Check Transfer Case Oil Change Transfer Case Oil* Tighten Wheel Bolts Lubricate Rear Knuckles † Inspect OPS Inspect Front and Rear Shocks Inspect Ball Joints...

  • Page 19: Accessories

    Accessories NOTE: For parts or accessories, contact your local Cub Cadet dealer. To locate the dealer nearest you call 877-282-8684 or log onto www.cubcadet.com. Description Horn (Requires Accessory Harness) Acrylic Windshield Glass Windshield Manual Wiper Kit Electric Wiper Kit Basic Lighting and Fuse Box Kit...

  • Page 20: Specifications

    Specifications NOTE: Specifications subject to change without notice. Engine/Electrical Dimensions Make Length/ Width 119” x 63.5” 20HP** Kohler Command® V-Twin OHV Tread Center F: 52”/ R: 50” Type/ Cylinders 4 Cycle Gas/ 2 Cylinders Height (Overall) 78” Displacement 38.0 cu. in. (624cc) Wheelbase 78”...

  • Page 21: Troubleshooting

    Troubleshooting Problem Cause(s) Engine will not start Battery has low voltage. Loose or corroded battery connections. Fuse is blown. Spark plug wire is loose or disconnected. Faulty spark plug or coil. No Fuel or improper fuel. Plugged fuel filter. Defective starter solenoid. Open-circuit in wiring.
  • Page 22 Problem Cause(s) Engine overheats Air cleaner element missing or plugged. Carburetor air intake tube plugged. Engine oil low. Engine operated too long at slow engine speed. Engine knocks Low engine speed. Stale or low octane fuel. Engine overloaded. Engine loses power Engine overheating.
  • Page 23 Problem Cause(s) Battery will not take a charge Dead battery. Loose or corroded connections. Sulfated or worn-out battery. Fluid level low. Difficult to shift Gears not lined up. Flip throttle and let it return to idle. If still hard to shift, contact your nearest Cub Cadet dealer.
  • Page 24 Notes...
  • Page 25 12 — n ectiOn Otes...
  • Page 26 CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS The California Air Resources Board and MTD Consumer Group Inc are pleased to explain the evaporative emission control system warranty on your 2008 utility vehicle. In California, new utility vehicle must be designed, built and equipped to meet the State’s stringent anti-smog standards. MTD Consumer Group Inc must warrant the EECS on your utility vehicle for the period of time listed below provided there has been no abuse, neglect or improper maintenance of your utility vehicle.

  • Page 27: Warranty

    WARRANTED PARTS: The repair or replacement of any warranted part otherwise eligible for warranty coverage may be excluded from such warranty coverage if MTD Consumer Group Inc demonstrates that the utility vehicle has been abused, neglected, or improperly maintained, and that such abuse, neglect, or improper maintenance was the direct cause of the need for repair or replacement of the part.
  • Page 28 CUB CADET LLC MANUFACTURER’S LIMITED WARRANTY FOR UTILITY VEHICLES The limited warranty set forth below is given by Cub Cadet LLC with b. Routine maintenance items such as lubricants, filters, tune-ups, respect to new merchandise purchased and used in the United States,...
