Safe Operation Practices • Set-Up • Operation • Service • Troubleshooting
O
Table of Contents
Important Safe Operation Practices ..................... 2
Introduction ............................................................. 6
Set-Up ....................................................................... 7
Controls & Operation .............................................. 8
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
NOTE: This Operator's Manual co vers several models. Features may vary by model. Not all features in this manual are applicable to all
models and the model depicted may differ from yours.
peratOr
Utility Vehicle
Challenger 4 x 4
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
'
M
s
anual
Product Care ...........................................................13
Specifications ..........................................................21
Warranties ............................................................. 26
WARNING
Form No. 769-12553
(November 2, 2017)
