Safety • Assembly • Operation • Tips & Techniques • Maintenance • Troubleshooting • Warranty
OPERATOR'S MANUAL
4x4 Utility Vehicle — Model Series C460
4x2 Utility Vehicle — Model Series C470
READ SAFETY RULES AND INSTRUCTIONS CAREFULLY BEFORE OPERATION
Warning: This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-
covered or grass-covered land unless the engine's exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any).
If a spark arrester is used, it should be maintained in effective working order by the operator. In the State of California the above is required by law
(Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester
for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland,
Ohio 44136-0019.
CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
PRINTED IN U.S.A.
IMPORTANT
FORM NO. 769-02244B
2/2/2007
Advertisement
Table of Contents
Related Manuals for Cub Cadet C460 Series
Summary of Contents for Cub Cadet C460 Series
- Page 1 (Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland, Ohio 44136-0019. CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 FORM NO. 769-02244B PRINTED IN U.S.A.
-
Page 2: Table Of Contents
If you have difficulty assembling this product or have any questions regarding the controls, operation or maintenance of this unit, contact the dealer from which you purchased this vehicle. To find a Cub Cadet Dealer nearest you choose from the options below: 1. - Page 3 WARNING To Avoid An Accident And Injury • Do not tow more than 1300 Lb. rolling weight (i.e., trailer plus cargo). • Spread load evenly. Never exceed 150 lb. tongue weight. • Go slow and use extra care when towing. Allow for Safety increased braking distance.
-
Page 4: Safe Operation Practices
WARNING: Engine Exhaust, some of its constituents, and certain vehicle compo- nents contain or emit chemicals known to State of California to cause cancer and birth defects or other reproductive harm. DANGER: This vehicle is designed to be operated according to the rules for safe operation in this Safe manual. - Page 5 Slope Operation 21. Improper use of the vehicle or failure to properly maintain it could result in decreased vehicle perfor- Slopes are a major factor related to loss of control and mance or personal injury. rollover accidents, which can result in severe injury or 22.
- Page 6 Cargo Box Lift d. Never carry small children, they may fall off and be seriously injured or interfere with safe vehicle 1. Stop vehicle on level ground and set Parking Brake operation. before raising cargo box. e. Use extreme care while approaching blind corners, 2.
-
Page 7: Safe Handling Of Gasoline
Never fuel machine indoors. c. Never secure any parts other than Cub Cadet g. Never remove gas cap or add fuel while the engine Practices approved accessories on the main frame or is hot or running. -
Page 8: Know Your Utility Vehicle
Know Your Utility Vehicle NOTE: Reference to right or left hand side of the utility vehicle is observed from the operating position. Know Your Utility Vehicle IMPORTANT Read the Engine operator’s manual before operating this vehicle to familiarize yourself with the engine controls and adjust- ments. -
Page 9: Brake Pedal
Accelerator Pedal The accelerator pedal is located on the right side of the floor beneath the dash panel. Depressing the accelerator pedal will move the vehicle in the direction selected on the gearshift. As the pedal is depressed, speed will increase to the maximum selected range. -
Page 10: Hour Meter
Hour Meter The hour meter is located in the center of the warning light cluster. It reads the elapsed time engine has run. See Figure 2. NOTE: Every 50 hours a “change oil” message will flash Know on the display for 2 minutes every time the tractor is started. - Page 11 WARNING: Always wear the seat belt when operating the utility vehicle equipped with a OPS. However, if the OPS is not present or has been removed, the seat belt must not be used. Know Adjustable Seat Lever Your The adjustable seat lever is located beneath the driver’s seat on the front side and it is used to move the seat forward and backward.
-
Page 12: Operating Your Utility Vehicle
WARNING: This is an off-road utility 2. Put unit back into Neutral. vehicle and it should not be oper- 3. Set parking brake and turn key switch to STOP ated on public highways. Know and position. comply with all laws and regulations 4. - Page 13 Raising & Lowering Cargo Box Engaging 4x4 (4x4 Only) The 4x4 switch is located on the right side of the dash panel. See Know Your Utility Vehicle. WARNING: To prevent the possibility of bodily injury from unintentional 1. To engage, stop or slow vehicle speed and push lowering of the cargo box, be sure up on the switch.
-
Page 14: Towing Loads
WARNING: The center of gravity 5. Do not load above height of cargo box front panel. changes as a loaded cargo box is Load could shift forward striking driver or passenger or raised. Do not allow rear wheel to cause driver to loose control of vehicle. hang over the edge of a loading 6. -
Page 15: Transporting Vehicle
Transporting Vehicle WARNING: Always wear the seat belt when operating the utility vehicle equipped with a OPS. However, if IMPORTANT: Never tow the vehicle. Transmission the OPS is not present or has been damage will occur if vehicle is towed. Haul the vehicle on removed, the seat belt must not be used. -
Page 16: Servicing Your Utility Vehicle
Clean Battery and Terminals Jumper Cables 1. Remove battery from vehicle. Always remove negative cable first when disconnecting. 2. Wash battery with solution of four tablespoons of baking soda to one gallon of water. Servicing 3. Rinse the battery with plain water and dry. 4. -
Page 17: Tire Pressure
Replacing Headlight Bulbs 1. Raise hood to get access to the headlight assembly. 2. Turn the bulb/socket assembly approximately a quarter turn counterclockwise to align its tabs with the notches of the reflector, then remove from the reflector. See Figure 6. Servicing 3. - Page 18 Protective Structure (OPS) Periodically (at least every six months) visually inspect the OPS for damage and loose fasteners. If damage is noted, contact your Cub Cadet dealer. If an accident has occurred which may have damaged the Servicing OPS, have the OPS thoroughly inspected by your Cub Cadet dealer.
-
Page 19: Drive Belt
100 hours or once a year. See Figure 11. If excessive wear appears, have ball joints or tie rod ends replaced by your local Cub Cadet dealer. - Page 20 Changing Brake Pads WARNING: Using an unstable lifting device and vehicle support may result in bodily injury. Use a safe lifting device and supports to work on raised Servicing vehicle. Your To gain access to the brake pads, remove the wheel as described in the Wheel Replacement Section.
- Page 21 Draining CVT Cover Drain CVT cover every 50 hours or after driving vehicle through more than 12” of water. 1. Remove CVT cover drain plug. See Figure 14. 2. Allow water to completely drain out. 3. Reinstall drain plug, and tighten securely. Servicing Cleaning The body panels are scratch and impact resistant...
-
Page 22: Service Chart
Electrical Accessory Harness (Standard With Limited Edition) Heavy Duty Alternator Kit Front Receiver NOTE: Availability of these accessories are subject to change. Please see your local Cub Cadet service dealer for the latest information regarding accessories for your utility vehicle. -
Page 23: Specifications
For parts or Alternator 12 Volt-15 Amp Regulated 11 1/2” ”H accessories, contact Headlights Two, 37.5 Watt Incandescent your local Cub Cadet Operation Wiring Automotive - Style Fused Control dealer. To locate the System Brake Type Four Wheel 8” Hydraulic Disc... -
Page 24: Troubleshooting
Spark plug is fouled. or corrections, Faulty spark plug or wire. contact your nearest Loose or corroded electrical connections. Cub Cadet service Stale or improper fuel. dealer or call Choke not being used or adjusted incorrectly. 1-877-282-8684. Faulty spark plug. - Page 25 Sulfate or worn-out battery. minor adjustments or corrections, Faulty starter. contact your nearest Low battery output. Starter crank slowly Cub Cadet service Sulfated or worn-out battery. dealer or call Engine oil too heavy. 1-877-282-8684. Loose or corroded connections. If you would like Entire electrical system Blown fuse.
- Page 26 CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS The California Air Resources Board and MTD Consumer Group Inc are pleased to explain the evaporative emission control system warranty on your 2006 utility vehicle. In California, new utility vehicle must be designed, built and equipped to meet the State’s stringent anti-smog standards. MTD Consumer Group Inc must warrant the EECS on your utility vehicle for the period of time listed below provided there has been no abuse, neglect or improper maintenance of your utility vehicle.
-
Page 27: Commercial Warranty
CADET DEALER. To locate the dealer in your area, please check for features of the product shall void this Warranty. You assume the a listing in the Yellow Pages or contact Cub Cadet LLC at P.O. Box risk and liability for loss, damage, or injury to you and your property... -
Page 28: Residential Warranty
MANUFACTURER’S LIMITED WARRANTY FOR The limited warranty set forth below is given by Cub Cadet LLC with e. Replacement parts that are not genuine Cub Cadet parts. respect to new merchandise purchased and used in the United States, its f. Service completed by someone other than an authorized service possessions and territories.
