Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty
O
'
M
peratOr
s
anual
4 x 4 Utility Vehicle — Models 37BK466D710, 37BK465D710
& 37BK46GD710
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA
Form No. 769-04929
(September 1, 2009)
Advertisement
Table of Contents
Related Manuals for Cub Cadet 37BK466D710
Summary of Contents for Cub Cadet 37BK466D710
- Page 1 Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty ’ peratOr anual 4 x 4 Utility Vehicle — Models 37BK466D710, 37BK465D710 & 37BK46GD710 WARNING READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
-
Page 2: Table Of Contents
Choose from the options below: ◊ Visit us on the web at www.cubcadet.com ◊ Locate your nearest Cub Cadet Dealer at (877) 282-8684 ◊ Write us at Cub Cadet LLC • P.O. Box 361131 • Cleveland, OH • 44136-0019... -
Page 3: Safe Operation Practices
Important Safe Operation Practices WARNING: This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury. - Page 4 Inspect area around vehicle before moving, especially in Always inspect your vehicle each time you use it to make reverse. Back up slowly. Always look down and behind sure it is in safe operating condition. Always follow the before and while backing to avoid a back-over accident. inspection and maintenance procedures and schedules Keep bystanders out of area.
- Page 5 When practical, remove gas-powered equipment Never secure any parts other than Cub Cadet from the truck or trailer and refuel it on the ground. approved accessories on the main frame or attach If this is not possible, then refuel such equipment on...
-
Page 6: Spark Arrestor
Never fuel machine indoors. Observe proper disposal laws and regulations for gas, oil, etc. to protect the environment. Never remove fuel cap or add fuel while the engine is hot or running. Allow engine to cool at least two Prior to disposal, determine the proper method to dispose minutes before refueling. - Page 7 Safety Symbols This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbol Description READ THE OPERATOR’S MANUAL(S) Read, understand, and follow all instructions in the manual(s) before attempting to assemble and operate WARNING—...
-
Page 8: Controls & Features
Controls and Features Figure 4-1 Glow Plug Light 4x4 Switch Ignition Switch 12 Volt Power Outlet Brake Pedal Accelerator Pedal Differential Lock Lever Shift Lever Parking Brake Lever Cup Holders Warning Light Cluster Seat Belts Engine Over-Temp Light Fuel Tank Read this operator’s manual, safety labels, and operating instructions on the vehicle before operating. -
Page 9: Accelerator Pedal
Accelerator Pedal Engine Over-Temp Light The accelerator pedal is located on the right side of the floor The engine over-temp light (red) is located on the dash panel on beneath the dash panel. Depressing the accelerator pedal will the right side of the warning light cluster. When lit, this indicates move the vehicle in the direction selected on the gearshift. -
Page 10: Seat Belts
NOTE: Every 50 hours a “change oil” message will flash on the display for 2 minutes every time the tractor is started. This message will repeat for the first two minutes after each 50 hour interval. The oil pressure indicator light will also flash when this display is active. -
Page 11: Operation
Operation Filling Fuel Tank Stopping Engine Stop vehicle on a level surface and apply parking brake. To stop utility vehicle, release accelerator pedal and depress brake pedal until vehicle comes to a complete Turn the ignition key to the STOP position and remove the stop. - Page 12 Release accelerator and apply brake pedal evenly and Electric Lift (Optional) firmly to slow down or stop. Park the vehicle safely and turn key to the RUN position. Engaging 4x4 Raise cargo box by pressing and holding top of electric lift switch.
-
Page 13: Towing Loads
Do not modify the hitch in any way. In the event of an accident, have the OPS carefully Transporting Vehicle inspected and, if necessary, replaced by your Cub Cadet dealer. Do not attempt to repair the OPS. IMPORTANT: Never tow the vehicle. Transmission damage will occur if vehicle is towed. -
Page 14: Maintenance & Adjustment
Maintenance & Adjustments Engine Use a permanent type antifreeze containing corrosion and rust inhibitors. Dilute the antifreeze with water at a 1 : 1 ratio to mix the coolant solution (50% antifreeze : 50% water). Air Filter NOTE: Distilled water is recommended for the coolant solution The engine air filter should be changed every 50 hours. -
Page 15: Servicing The Fuel Filter
The engine coolant should be drained and replaced with new Stop the engine and raise the passenger seat by removing coolant solution every 2 years or 500 hours. See your Cub Cadet the wing nut securing it to the frame. - Page 16 The fuel injector nozzles should be checked and serviced after WARNING: The battery produces a flammable and every 2000 hours of engine operation. Contact your Cub Cadet explosive gas. Do not smoke near battery. Wear eye dealer. protection and gloves when handling the battery.
-
Page 17: Tire Pressure
If damage is noted, contact your Cub Cadet dealer. If an accident has occurred which may have damaged the OPS, have the OPS thoroughly inspected by your Cub Cadet dealer. WARNING: To ensure the structural integrity of the OPS to provide operator protection, do not attempt to straighten or weld the OPS. - Page 18 100 hours or once a year. See Fig. 6-8. If excessive wear appears, have ball joints or tie rod ends replaced by your local Cub Cadet dealer. Figure 6-10 Allow water to completely drain out.
-
Page 19: Service
Service Fuses Headlight Bulbs Unlatch and lift hood forward to get access to under the Raise hood to get access to the headlight assembly. dash panel. Turn the bulb/socket assembly approximately a quarter turn counterclockwise to align its tabs with the notches of Remove fuse holder cover. -
Page 20: Cub Cadet Dealer
Torque the mounting bolts to 22 to 26 ft. lbs. Replace wheel as described in Wheel section. Belts IMPORTANT: Several components must be removed in order to change the vehicle’s belts. See your Cub Cadet Dealer to have your belts replaced. 7— s ectiOn ervice... -
Page 21: Maintenance Chart
Maintenance Chart Maintenance Schedule Before Each First 10 Every 20 Every 50 Every 100 Every 500 Service Hours Hours/2 mo. Hours Hrs. or Yearly Hrs. or 2 Yrs. Dates Check Transfer Case Oil Change Transfer Case Oil* Tighten Wheel Bolts Change Air Filter^ Check Engine Coolant Level Change Engine Coolant... -
Page 22: Accessories
Accessories NOTE: For parts or accessories, contact your local Cub Cadet dealer. To locate the dealer nearest you call 877-282-8684 or log onto www.cubcadet.com. Description Description Horn Gadget/Grab Bar Acrylic Windshield AM/FM CD Radio 14” Aluminum Rims & Off-Road Tires (Set of 4) 12”... -
Page 23: Specifications
Specifications NOTE: Specifications subject to change without notice. Engine/Electrical Dimensions Make 21.9HP* Yanmar® Length/ Width 119” x 63.5” Type/ Cylinders 4 Cycle Diesel/ 3 Cylinders Tread Center F: 52”/ R: 50” Displacement 854cc Height (Overall) 73” Maximum Torque 36.9 ft. lb. @ 2400 RPM Wheelbase 78”... -
Page 24: Troubleshooting
Troubleshooting Problem Cause(s) Engine will not start Battery has low voltage. Loose or corroded battery connections. Fuse is blown. No Fuel or improper fuel. Plugged fuel filter. Air or water is in the fuel system. In Winter, oil viscosity increases, and engine revolution is slow. Defective starter solenoid. - Page 25 Problem Cause(s) Engine overheats Engine overloaded. Low coolant level. Dirty radiator core or grille screen. Coolant flow route corroded. Air cleaner element missing or plugged. Engine oil low. Engine operated too long at slow engine speed. Engine loses power Engine overheating. Too much oil in engine.
- Page 26 Problem Cause(s) Battery will not take a charge Dead battery. Loose or corroded connections. Sulfated or worn-out battery. Fluid level low. Difficult to shift Gears not lined up. Flip throttle and let it return to idle. If still hard to shift, contact your nearest Cub Cadet dealer.
- Page 27 Notes...
- Page 28 Otes...
- Page 29 Otes...
- Page 30 FEDERAL and/or CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS MTD Consumer Group Inc, the United States Environmental Protection Agency (EPA), and, for those products certified for sale in the state of California, the California Air Resources Board (CARB) are pleased to explain the emission (evaporative and/or exhaust) control system (ECS) warranty on your outdoor 2006 and later small off-road spark-ignited engine and equipment (outdoor equipment engine) In California, new outdoor equipment engines must be designed, built and equipped to meet the State’s stringent anti-smog standards (in other states, 1997 and later model year equipment must be designed, built, and equipped to meet the U.S.
- Page 31 WARRANTED PARTS: The repair or replacement of any warranted part otherwise eligible for warranty coverage may be excluded from such warranty coverage if MTD Consumer Group Inc demonstrates that the outdoor equipment engine has been abused, neglected, or improperly maintained, and that such abuse, neglect, or improper mainte- nance was the direct cause of the need for repair or replacement of the part.
- Page 32 CUB CADET LLC MANUFACTURER’S LIMITED WARRANTY FOR UTILITY VEHICLES The limited warranty set forth below is given by Cub Cadet LLC with b. Routine maintenance items such as lubricants, filters, tune-ups, respect to new merchandise purchased and used in the United States,...
