AMP Research PowerStep 76263-01A Installation Manual page 5

A M P R E S E A R C H P O W E R S T E P
16
x4
LED Lamp
20
Rear Support Bracket
(Passenger rear)
SPRINTER POWERSTEP DRILL TEMPLATE
Use center punch, pilot drill (1/8"),
then drill final hole size (17/32")
BEND DOWN 90 Degrees
23
x2
Drill Template
www.amp-research.com
17
x8
Butt Connector
21
x2
Support Bracket (Driver
rear and Passenger front)
5/14
– S P R I N T E R
T M
PARTS LIST AND HARDWARE IDENTIFICATION
18
Rivet Nut Tool
19
M8 small head
Hex bolt
22
Bracket (Driver Front)
IM76263 rev 01.21.20
