AMP Research PowerStep 76263-01A Installation Manual page 3

A M P R E S E A R C H P O W E R S T E P – S P R I N T E R
T M
A
F
C
E
(A) End cap left (x1)
D
(B) End cap right (x1)
B
(C) T-nut insert (x2)
(D) Socket cap screw (x2)
(E) End cap wedge right (x1)
1
(F) End cap wedge left (x1)
Running board assembly
3a
2a
Idler Linkage Assembly (Passenger)
Motor Linkage Assembly (Passenger)
2b 3b
Motor Linkage Assembly (Driver) Idler Linkage Assembly (Driver)
