- Page 1 ES5385.1 Carrier Board for Resistor Cascade (12 Sockets) PB5385RES.1-A Resistor Cascade Piggyback (20 Ohm…1 MOhm) User’s Guide...
- Page 2 The data in this document may not be altered or amended without special noti- fication from ETAS GmbH. ETAS GmbH undertakes no further obligation in rela- tion to this document. The software described in it can only be used if the customer is in possession of a general license agreement or single license.
-
Page 3: Table Of Contents
2.4.2 Assembling the PB5385RES.1-A Resistor Cascade Piggyback on the ES5385.1 Carrier Board for Resistor Cascade ....23 2.4.3 Inserting the ES5385.1 Carrier Board for Resistor Cascade into the slot... - Page 4 6 ETAS Contact Addresses ........
-
Page 5: Introduction
ETAS Introduction Introduction This User’s Guide describes the ES5385.1 Carrier Board for Resistor Cascade. Cables and modules are not part of the delivery scope. PB5385RES.1-A Resistor Cascade Piggybacks must be ordered separately. CAUTION! Some components of the ES5385.1 Carrier Board for Resistor Cas- cade can be damaged or destroyed by electrostatic discharges. -
Page 6: Features
Introduction ETAS Features The ES5385.1 Carrier Board for Resistor Cascade is used to accommodate up to twelve PB5385RES.1-A Resistor Cascade Piggybacks. Fig. 1-1 Front Panel and Connection Side of the ES5385.1 Carrier Board for Resistor Cascade ES5385.1 Carrier Board for Resistor Cascade PB5385RES.1-A - User’s Guide... - Page 7 ETAS Introduction The ES5385.1 Carrier Board for Resistor Cascade comes without a PB5385RES.1- A Resistor Cascade Piggyback. The ES5385.1 is delivered as shown in Figure 1-2. Fig. 1-2 View of the ES5385.1 Carrier Board for Resistor Cascade (Unassem- bled) from the Side Figure 1-3 shows the PB5385RES.1-A Resistor Cascade Piggyback.
- Page 8 The ES5385.1 Carrier Board for Resistor Cascade is only designed for the ETAS PB5385RES.1-A Resistor Cascade Piggyback. Installing boards that are not supported may result in damage to the ES5385.1, the ES5300.1-A or the ES5300.1-B and/or to the non-supported board.
- Page 9 ETAS Introduction The function units of the ES5385.1 Carrier Board for Resistor Cascade are shown in the following block diagram: Fig. 1-5 Block Diagram of the ES5385.1 Carrier Board for Resistor Cascade with PB5385RES.1-A Resistor Cascade Piggyback All resistor channels are galvanically isolated both from each other and from the housing potential of the ES5300.1-A Housing or ES5300.1-B Housing.
-
Page 10: Basic Safety Instructions
Note Please read this User’s Guide carefully before using the product! ETAS GmbH cannot be made liable for damage which is caused by incorrect use and handling and not adhering to the safety instructions. 1.2.3... -
Page 11: Intended Use
ES5300.1-A Housing or ES5300.1-B Housing and must not be oper- ated as a stand-alone unit. The use of the ES5385.1 in an ES5300.1-A Housing or ES5300.1-B Housing is as follows: • In industrial lab facilities or at industrial workplaces •... - Page 12 Switch off the ES5300.1-A Housing or the ES5300.1-B Housing and external power supplies and unplug the power plug and other connectors attached to the plug-in board. Wait at least three minutes before removing the plug-in board. ES5385.1 Carrier Board for Resistor Cascade PB5385RES.1-A - User’s Guide...
- Page 13 To avoid damages to the hardware from electrostatic discharge, please observe the following precautionary measures: CAUTION! Some components of the ES5385.1 Carrier Board for Resistor Cas- cade can be damaged or destroyed by electrostatic discharges. Leave the board in its transport packaging until it is installed.
- Page 14 To avoid injuries and hardware damages, please observe the following precau- tionary measures: • Do not apply any voltages to the ports of the ES5385.1 Carrier Board for Resistor Cascade that do not correspond to the specifications of the rele- vant port.
-
Page 15: Identifications On The Product
The EU Directive 2002/95/EU limits the use of certain dangerous materials for electrical and electronic devices (RoHS conformity). ETAS confirms that the product corresponds to this directive which is applicable in the European Union. ES5385.1 Carrier Board for Resistor Cascade PB5385RES.1-A - User’s Guide... -
Page 16: Kc Marking
RoHS marking affixed to the product or its packaging. 1.3.3 KC Marking With the KC mark attached to the product and its packaging, ETAS confirms that the product has been registered in accordance with the product-specific KCC guidelines of the Republic of Korea. -
Page 17: About This Manual
This section describes the various connectors of the ES5385.1 Carrier Board for Resistor Cascade. • "Technical Data and Standards" on page 33 This chapter contains the technical data on the ES5385.1 Carrier Board for Resistor Cascade. 1.6.1 Using this Manual Representation of Information All activities to be carried out by the user are shown in what we call a "Use-... - Page 18 Content markings and newly introduced logical and arithmetic is not possi- terms are shown in italics. ble. Important notes for the user are shown as follows: Note Important note for the user. ES5385.1 Carrier Board for Resistor Cascade PB5385RES.1-A - User’s Guide...
-
Page 19: Features And Functions
Cascade Piggybacks must be ordered separately. Power Supply Power is supplied to the ES5385.1 Carrier Board for Resistor Cascade and the PB5385RES.1-A Resistor Cascade Piggyback via the backplane of the ES5300.1- A or ES5300.1-B. The CO200 connector is responsible for the electrical connec- tion. -
Page 20: Fuses
ES5385.1 Carrier Board for Resistor Cascade (see page 9). If a fuse is faulty, we recommend you send the board to ETAS for a thorough check using one of the addresses listed in the chapter "ETAS Contact Addresses"... -
Page 21: Fuse Specification
ETAS Features and Functions There are three fuses on the ES5385.1 Carrier Board for Resistor Cascade to pro- tect the voltages from the ES5300.1-A or ES5300.1-B backplane. Fig. 2-2 Position of the Fuses on the ES5385.1 Carrier Board for Resistor Cas- cade 2.3.1... -
Page 22: Assembly
Features and Functions ETAS Assembly 2.4.1 Getting Ready to Assemble the ES5385.1 Carrier Board for Resistor Cascade in the ES5300.1-A Housing or ES5300.1-B Housing Before starting, ensure you have ESD-compliant conditions at your workplace. CAUTION! Some components of the ES5385.1 Carrier Board for Resistor Cas- cade can be damaged or destroyed by electrostatic discharges. -
Page 23: Assembling The Pb5385Res.1-A Resistor Cascade Piggyback On The Es5385.1 Carrier Board For Resistor Cascade
Cascade Piggyback on the ES5385.1 Carrier Board for Resistor Cascade: 1. Align the Resistor Cascade Module to the relevant guide pin (orange- dashed rectangles in Fig. 2-4) of every slot of the ES5385.1 Carrier Board for Resistor Cascade. 2. The alignment also has to correspond to the electrical interface (contact strip)! 3. - Page 24 (indicated by a red flash in Fig. 2-4). CAUTION! Ensure the boards are aligned correctly so that no connector pins can be bent. Place the ES5385.1 Carrier Board for Resistor Cascade flat on an ESD-compliant, clean surface. ES5385.1 Carrier Board for Resistor Cascade PB5385RES.1-A - User’s Guide...
-
Page 25: Inserting The Es5385.1 Carrier Board For Resistor Cascade Into The Slot
ETAS Features and Functions 2.4.3 Inserting the ES5385.1 Carrier Board for Resistor Cascade into the slot CAUTION! When correctly assembled, the ES5385.1 Carrier Board for Resistor Cascade occupies just one slot of the ES5300.1-A Housing or ES5300.1-B Housing. If adjacent boards or front panels of adjacent slots collide with the ES5385.1, you have not assembled the combination of PB5385RES.1-... - Page 26 Features and Functions ETAS ES5385.1 Carrier Board for Resistor Cascade PB5385RES.1-A - User’s Guide...
-
Page 27: Pin Assignment And Connections
ETAS Pin Assignment and Connections Pin Assignment and Connections This section describes the various connectors of the ES5385.1 Carrier Board for Resistor Cascade. • "Backplane Connector (CO200)" on page 27 • "VG 96 (CO601) I/O Interface" on page 29 Backplane Connector (CO200) - Page 28 BN_4 BN_5 n.c. n.c. n.c. n.c. n.c. n.c. 12-Shield SPI_CS_A_n SPI_CS_B_n n.c. n.c. n.c. n.c. n.c. n.c. 11-Shield SPI_CLK SPI_MOSI n.c. n.c. n.c. n.c. n.c. n.c. 10-Shield SPI_MISO PCIE_WAKEn n.c. n.c. n.c. n.c. n.c. n.c. 9-Shield n.c. n.c. n.c. n.c. n.c.
-
Page 29: Vg 96 (Co601) I/O Interface
Channel 1 Reference 1 Channel 1 n. c. n. c. n. c. Channel 0 Reference 0 Channel 0 Tab. 3-1 Pin Assignment of the Resistor Channels on CO601 ES5385.1 Carrier Board for Resistor Cascade PB5385RES.1-A - User’s Guide... - Page 30 ECU and external loads). The cables used must, in partic- ular, be suitable for the currents, voltages and temperatures which occur and must be flameretardant in accordance with one of the fol- lowing standards IEC60332-1-2, IEC60332-2-2, UL2556/UL1581VW-1! ES5385.1 Carrier Board for Resistor Cascade PB5385RES.1-A - User’s Guide...
- Page 31 The function of the reference pin only applies when attention is paid to noise immunity when defining the ground/cabling concept. (This means, for exam- ple, signal flow with low impedance, defined reference potentials, low contact resistance, shielded configuration, no crosstalk). ES5385.1 Carrier Board for Resistor Cascade PB5385RES.1-A - User’s Guide...
- Page 32 Pin Assignment and Connections ETAS ES5385.1 Carrier Board for Resistor Cascade PB5385RES.1-A - User’s Guide...
-
Page 33: Technical Data And Standards
ETAS Technical Data and Standards Technical Data and Standards Technical Data This chapter contains the technical data on the ES5385.1 Carrier Board for Resis- tor Cascade. Voltages, Currents, Power Consumption, Characteristics Maximum voltage at inputs and outputs (CO601); PIN A ±60 V for max. -
Page 34: Fulfilled Standards And Norms
Physical Dimensions Height Width 5 HP Weight 0,5 kg Fulfilled Standards and Norms The ES5385.1 Carrier Board for Resistor Cascade complies with the following standards and norms: Standard Testing IEC 61326-1 Electrical equipment for measurement, control and laboratory use –... -
Page 35: Ordering Information
Cascade (12 Sockets) K_ES5385.1 Calibration Service for K_ES5385.1 F-00K-109-678 ES5385.1 PB5385RES.1-A Resistor Cascade Pig- PB5385RES.1-A F-00K-109-676 gyback (20 Ohm…1 MOhm) Scope of Supply Number ES5385.1 Carrier Board for Resistor Cascade ES5385.1 Carrier Board for Resistor Cascade PB5385RES.1-A - User’s Guide... - Page 36 Ordering Information ETAS ES5385.1 Carrier Board for Resistor Cascade PB5385RES.1-A - User’s Guide...
-
Page 37: Etas Contact Addresses
For details of your local sales office as well as your local technical support team and product hotlines, take a look at the ETAS website: ETAS subsidiaries WWW: www.etas.com/en/contact.php ETAS technical support WWW: www.etas.com/en/hotlines.php ES5385.1 Carrier Board for Resistor Cascade PB5385RES.1-A - User’s Guide... - Page 38 ETAS Contact Addresses ETAS ES5385.1 Carrier Board for Resistor Cascade PB5385RES.1-A - User’s Guide...
-
Page 39: Index
European Union 15 Features 19 Safety instructions 10 Fuse specification 21 Signal lines 34 Fuses 20 Standards 34 Storage conditions 33 General safety information 10 Taking back the product 16 ES5385.1 Carrier Board for Resistor Cascade PB5385RES.1-A - User’s Guide... - Page 40 Index ETAS Technical data 33 Waste Electrical and Electronic Equip- ment 16 WEEE take-back system 16 ES5385.1 Carrier Board for Resistor Cascade PB5385RES.1-A - User’s Guide...
