Exerpeutic 4230 Owner's Manual

Exerpeutic 4230 Owner's Manual

Momentum bike
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
®
Momentum Bike
IMPORTANT: Read all instructions carefully before using this product.
Retain this owner's manual for future reference.
The specifications of this product may vary from this photo, subject to
change without notice.
OWNER'S MANUAL
4230.3-071918

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4230 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Exerpeutic 4230

Summary of Contents for Exerpeutic 4230

  • Page 1 ® Momentum Bike IMPORTANT: Read all instructions carefully before using this product. Retain this owner’s manual for future reference. The specifications of this product may vary from this photo, subject to change without notice. OWNER’S MANUAL 4230.3-071918...
  • Page 2 PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE. STOP. Contact customer service if you have any questions regarding assembly or proper operation of the machine. Email us at: Service@paradigmhw.com Or call us at: 1-844-641-7921 Hours: 8:00 am to 5:00 pm (PST) Monday thru Friday...

  • Page 3: Table Of Contents

    TABLE OF CONTENT SERVICE ------------------------------------------------------------------------ LABEL PLACEMENT --------------------------------------------------------- IMPORTANT SAFETY GUIDELINES ------------------------------------- OVERVIEW DRAWING ------------------------------------------------------ PARTS LIST ------------------------------------------------------------------- HARDWARE & TOOLS PACK ------------------------------------------- REMOVE THE METAL BAR ------------------------------------------------ ASSEMBLY ---------------------------------------------------------------------- ADJUSTMENTS --------------------------------------------------------------- TROUBLESHOOTING ------------------------------------------------------- TRANSPORT & STORAGE ------------------------------------------------ WARRANTY -------------------------------------------------------------------- PARTS REQUEST FORM---------------------------------------------------...

  • Page 4: Service

    SERVICE IMPORTANT: FOR NORTH AMERICA ONLY For damaged or defective product, questions, replacement parts or any other service support, please contact our customer service department by the below methods: For The Best Service, please Email: service@paradigmhw.com Response Time: 1-2 Business Days Emailing us with the information above will be the best method to receive a response during peak business hours Website:...

  • Page 5: Label Placement

    LABEL PLACEMENT...

  • Page 6: Important Safety Guidelines

    IMPORTANT SAFETY GUIDELINES Read all instructions before using the equipment. When using the equipment, basic precautions should always be followed. WARNING - To reduce the risk of injury to persons, read and under the following: Make sure your equipment is correctly assembled before you use it. Be sure all screws, nuts, and bolts are tightened prior to use.
  • Page 7 IMPORTANT SAFETY GUIDELINES Do NOT use this equipment if you have any of the following conditions or ailments:  Pregnancy  Extreme obesity  Middle ear infection  Hiatus hernia or Ventral hernia  Glaucoma, retinal detachment or conjunctivitis  Use of anticoagulants including Aspirin in high doses. ...

  • Page 8: Overview Drawing

    OVERVIEW DRAWING...

  • Page 9: Parts List

    PARTS LIST Description Description 1R Right Pedal Self-Drilling Bolt ST4.8x13 1L Left Pedal Flange Nut M10x1.25 End Cap Crank Cover Carriage Bolt M8x42 Bracket Knob Rear Stabilizer Lock Nut M8 Flat Washer Ø8 Bluetooth Bracket Cap Nut M8 Left Crank Spring Knob Crank Cover Plastic Sleeve...
  • Page 10 PARTS LIST Description Description Fixing Sleeve φ20x34 54 Self-Tapping ScrewST4.0x12 55 Bolt M8x40 Nylon Washer M10 56 Wheel φ50x23 Hex Nut M10 Nylon Washer φ20xφ14x2.0 57 Magnet Sensor 58 Thin Hex Nut M12x1.25 Spring 18x62 59 Flywheel Sleeve Axle 60 Bearing 6001ZZ Square Bushing 18x18x1.2 61 Flywheel Silicon Pad...

  • Page 11: Hardware & Tools Pack

    HARDWARE & TOOLS PACK...

  • Page 12: Remove The Metal Bar

    REMOVE THE METAL TUBE TOOL 6mm Allen Wrench NOTE* Have a second person help you hold the Main Frame (16) while you remove the tubes and during STEP 1. Remove the Metal Tubes (B) from the Main Frame (16) by removing the bolts (A) using 6mm Allen Wrench provided.

  • Page 13: Assembly

    ASSEMBLY TOOL: Double Wrench 1PC STEP 1 1a. Front Stabilizer Installation: Lift up the front of the Main Frame (16), and attach the Front Stabilizer (15) onto the front bracket of the Main Frame (16) with two Carriage Bolts (3), two Flat Washers (5), and two Cap Nuts (6).
  • Page 14 ASSEMBLY TOOL: Multi Hex Tool with Phillips Screwdriver STEP 2 2a. Cup Holder Installation: Remove two Screws (25) from the Main Frame (16). Attach the Cup Holder (24) onto the Main Frame (16), and tighten with two Philips Screws (25) using the Multi Hex Tool with Phillips Screwdriver provided.
  • Page 15 ASSEMBLY TOOL 6mm Allen Wrench Fig. A STEP 3 3a. Installing the Front Post to the Main Frame: Insert the Front Post (17) into the Main Frame (16). Then secure and tighten with the Spring Knob (7). TIP : When adjusting the height of Front Post (17), the STOP line cannot be higher than the edge of the plastic bushing.
  • Page 16 ASSEMBLY TOOL: 5mm Allen Wrench Double Wrench 1PC Fig. B STEP 4 4a. Installing the Seat Post to the Main Frame: Insert the Seat Post (10) into the Main Frame (16). Then secure it with the Spring Knob (7). TIP: When adjusting the height of Seat Post (10), the STOP line cannot be higher than the edge of the plastic bushing.
  • Page 17 ASSEMBLY TOOL: Multi Hex Tool with Phillips Screwdriver IMPORTANT: Ensure that the Right Pedal (1R) matches up with the Right Crank (36) and the Left Pedal (1L) matches up with the Left Crank (33). If reversed, the cranks may become damaged or stripped.
  • Page 18 ASSEMBLY Battery cover STEP 6 6a. BATTERY INSTALLATION: Remove the Battery Cover from the Console (32) and install Two AAA batteries provided into the battery tray in the correct polarity. Please be sure to install batteries in correct order or damage will occur. When the batteries are installed the red battery indicator light will blink three times.

  • Page 19: Adjustments

    ADJUSTMENTS Foot Pad (27) Front Stabilizer (15) Rear Stabilizer (4) Foot Pad (14) Adjusting the Foot Pad Turn the Foot Pad (14) on the Front and Rear Stabilizers (15) & (4) as needed to level the bike. Proper leveling will reduce noises and wobbling. Brake Knob (30) Adjusting the Brake Knob To increase the tension, turn the Brake Knob (30) in a CLOCKWISE direction.
  • Page 20 ADJUSTMENTS Fig. C Front Post (17) Spring Knob (7) Adjusting the Handlebar Height TIP: When adjusting the height of Front Post (17), the STOP line cannot be higher than the edge of plastic bushing. See Fig. C. Loosen the Spring Knob (7) by turning it COUNTER-CLOCKWISE direction until it can be pulled out.
  • Page 21 ADJUSTMENTS Seat Bracket (12) Spring Knob (7) Adjusting the Seat Forward or Back: Loosen the Spring Knob (7) by turning it in a COUNTER-CLOCKWISE direction. Slide the Seat Bracket (12) in a forward direction to the suitable position. Lock the Seat Bracket (12) in place by turning it in a CLOCKWISE direction.

  • Page 22: Troubleshooting

    TROUBLESHOOTING & MAINTENANCE TROUBLE SHOOTING 1. PROBLEM: The bike wobbles when in use. 1) SOLUTION: Turn the Foot Pads (14) on the Front and Rear Stabilizer (15) & (4) or as needed to level the bike. 2. PROBLEM: The bike makes a squeaking noise when in use. 1) SOLUTION: The bolts may be loose on the recumbent bike.

  • Page 23: Transport & Storage

    TRANSPORT & STORAGE Transporting the Bike Pull the Handlebar (18) with both hands until the Wheels (56) on the Front Stabilizer (15) make contact with the ground. Pull or Push the Bike to the desired storage area before gently lowering the Bike. Always maintain both hands on the Bike during transportation. Storage Store the bike in a clean and dry environment away from pets and children.

  • Page 24: Warranty

    WARRANTY MANUFACTURER’S LIMITED WARRANTY Paradigm Health & Wellness warrants to the original purchaser that this product is free from defects in material and workmanship when used for the purpose intended, under the conditions that it has been installed and operated in accordance with Paradigm’s Owner’s Manual.

  • Page 25: Parts Request Form

    PARTS REQUEST FORM Paradigm Health & Wellness, Inc. EMAIL THIS FORM WITH YOUR RECEIPT OF PURCHASE TO Service@paradigmhw.com NAME:_____________________________________________________________________________________ ADDRESS:__________________________________________________________________________________ CITY:________________________ STATE:_____________ ZIP:_______________________________________ TELEPHONE: (Day)______________________________________________________________________ (Night)_____________________________________________________________________ SERIAL#:___________________________________________________________________________________ MODEL#:___________________________________________________________________________________ PURCHASE DATE:___________________________________________________________________________ PLACE OF PURCHASE:_______________________________________________________________________ PART # DESCRIPTION “YOUR ORDER WILL BE PROCESSED WITHIN 3 BUSINESS DAYS” This form can also be faxed to #: 626-810-2166...
