Mec 1330SE Service & Parts Manual page 77

Secton 14 - Platform
Page 73
Item Part Number
1 41578
2 41127
3 41579
4 41271
5 53063
6 41134
7 50047
8 50000
9 50135
10 41273
11 41267
12 41131
13 41269
14 41360
15 50290
16 41272
17 41275
18 41128
19 53051
20 50000
21 50294
22 41277
23 41278
24 41574
25 41581
26 50447
27 50001
28 50048
29 91598
30 92007
31 91597
-- 53040
32 92008
1330SE - Servce & Parts Manual
Description
Platform Guard Rail
Hinge A
Platform Guard Rail
Connector Kit
HHMS M04-0.70 × 8
Clip
NNYL M06 × 1.00
WSHR M06 Standard Flat
HHCS M06-1.25 × 50
Waterproof Joint
Circlip
Bearing
Roller
Roller Installation
HHCS M08-1.25 × 40
Platform Deck Assembly
Shield Sleeve
Hinge B
HHMS M06-1.00 × 16
WSHR M06 Standard Flat
HHCS M06-1.00 × 45
Spring
Latch
Entry Gate
Door Support Bracket
HHCS M08-1.25 × 18
WSHR M08 Standard Flat
NNYL M08 × 1.25
Cover, Outlet Box Weatherproof
Outlet, 15A 120V GFCI
Outlet Box, 1/2" Weatherproof
HHSM M08-15 × 0.50
Strain Relief 0.50"
November 2019
Qty������
1
1
1
1
1
1
11
15
10
1
2
2
2
2
8
1
1
1
12
12
1
1
1
1
1
1
1
1
1
1
1
4
1
