Mec 1330SE Service & Parts Manual page 61

Secton 12 - Chasss
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
Page 57
Part Number
REF Hydraulic Power Unit (Refer to Page 60)
50127 SHCS M10-1.50 × 30
53054 WSHR M10 Spring Washer
50002 WSHR M10 Standard Flat
41947 ECU Assembly Kit
41329 Sleeve Pipe
53067 SHCS M05-0.80 × 40
41330 Battery
41331 DC Contactor
53068 CSCS M05-0.80 × 8
53043 WSHR M05 Spring Washer
53038 WSHR M05 Standard Flat
41332 Towline
53138 SHCS M06-1.00 × 16
41333 Fix Panel
50591 BHCS M05-0.80 × 20
41250 Traction Module
53035 BHCS M05-0.80 × 16
41334 Relay
41251 Fuse
53045 HHMS M05-0.80 × 14
50000 WSHR M06 Standard Flat
50047 NNYL M06 × 1.00
41335 Lock Latch
50028 HHCS M06-1.00 × 20
41252 Emergency Down Cable
53044 SHMS M05-0.80 × 10
41336 Battery Box Weldment
41065 Power Switch
41254 Charger
50591 BHCS M05-0.80 × 20
41255 Glide Track
50524 NNYL M05-0.80
50034 HHCS M10-1.50 × 30
41337 Fix Panel
92107 Fuse Holder ATO/ATC Black 16GA
94231 Fuse 2 Amp ATO
93099 Fuse 10 Amp
REF - Reference
1330SE - Servce & Parts Manual
Description
November 2019
Qty������
1
2
2
2
1
1
2
2
1
3
15
23
1
4
1
4
1
4
1
1
2
8
8
2
8
1
6
1
1
1
8
2
8
2
1
2
1
1
