Mec 1330SE Service & Parts Manual page 79

Secton 14 - Platform
Item Part Number
1 41279
2 41283
3 41890
4 41282
5 50258
6 53035
7 41120
8 50524
9 50001
10 50018
11 41280
12 50016
13 41361
14 50030
15 53055
16 41140
17 41284
18 53045
19 53069
20 41360
21 41141
22 41131
23 41267
24 8909
-- 50191
-- 50238
Page 75
Platform Guardrail
Platform Guardrail
Upper Control Box
Mounting BKT/Platform Control Box
HHCS M08-1.25 × 10
BHCS M05-0.80 × 16
Rubber Gasket
NNYL M05-0.80
WSHR M08 Standard Flat
HHCS M08-1.25 × 80
Platform Guardrail
HHCS M08-1.25 × 55
Platform Extension
HHCS M08-1.25 × 20
WSHR M08 Spring Washer
Locking Device
Slippage Of Crutch
HHMS M05-0.80 × 14
CSCS M06-1.00 × 20
Roller Installation
Roller
Bearing
Circlip
Enclosure Service Manual
THMS M10-32 × 0.50
NNYL M10-32
1330SE - Servce & Parts Manual
Description
November 2019
Qty������
1
1
1
1
4
2
2
12
12
12
1
8
1
2
2
1
2
8
8
2
2
2
2
1
4
4
