Section 3 - Specifications; SpecFCatOns - Mec 1330SE Service & Parts Manual

Secton 3 - Specfcatons
Working Height*
Platform Height
Maximum Drive Height
Stowed Height
Guardrail Height
Toeboard Height
Machine Weight** (Unloaded)
Lift Capacity
Deck Extension Capacity
Maximum Occupants
Length-Stowed (Overall)
Length-Stowed (Ladder Removed)
Platform Length (Extended)
Platform Length (Retracted)
Width (Overall)
Platform Width (Outside)
Wheel Base
Turning Radius - Inside
Ground Clearance - Stowed
Ground Clearance - Elevated
Drive Speed (Proportional)
Gradability
Maximum Side Slope - Stowed
Ground Pressure/Wheel
Maximum Wheel Load
Occupied Floor Pressure
Maximum Operating Wind Speed
Tire Size
Lug Nut Torque
Hydraulic Pressure
Power System Voltage
Battery Charger
Batteries
Meets applicable requirements of ANSI A92.6-2006.
*Working Height adds 6 feet (2 m) to platform height. **Weight may increase with certain options.
*** Uniform Pressure of 1330SE can be reduced to 111.2 (542.93 kg/sq.M) (unloaded) to 142.2 (694.3 kg/
sq.M) (loaded) by extending the slide out platform
Page 4
Specifications Specifications
Top Guardrail
Platform Floor
Total
Stowed
Raised or Extended
Input
Output
1330SE - Servce & Parts Manual
19 ft
13 ft
13 ft
74 in
35 in
39 in
6 in
1,900 lb
530 lb
1 Person / 250lb (113 kg)
2
58 in
51 in
75 in
51 in
30 in
27.5 in
41 in
18 in
2.5 in
0.6 in
0-2.5 mph
0-0.7 mph
25%/14°
5°
112 psi
730 lb
234 psf
28 mph / 12.5 m/sec (45 km/h)
9 × 3 inch/230 × 80mm
19 ft-lb / 25.5 Nm, secured with cotter pin
2250 psi/ 155 bar
24 Volt DC
110-230 V AC, 50-60 Hz
24 Volt DC
Two 12-Volt deep cycle; 85Ah
November 2019
6 m
4 m
4 m
1.9 m
0.9 m
1 m
15 cm
860 kg
240 kg
1.5 m
1.3 m
1.9 m
1.3 m
76 cm
70 cm
1 m
45 cm
6 cm
1.5 cm
0-4 km/h
0-1.1 km/h
2
7.9 kg/cm
331 kg
1,138 kg/m 2
