Secton 8 - Emergency Systems And Procedures
Free-Wheel Configuration For Winching Or Towing
The machine can be winched or towed short distances at speeds not to exceed 2.5 MPH (4 km/h).
Before towing or winching the machine, it is necessary to release the brakes. Reset the brakes after
towing or winching.
Push Down
& Hold
Turn to
Ground
ART_4998
Page 12
RUNAWAY HAZARD!
AFTER RELEASING THE BRAKES THERE IS NOTHING TO STOP
MACHINE TRAVEL������ MACHINE WILL ROLL FREELY ON SLOPES������
ALWAYS CHOCK THE WHEELS BEFORE MANUALLY RELEASING THE
BRAKES������
Disengage Brakes Before Towing Or Winching
1. Chock the wheels.
2. Turn the Key Switch to the OFF position.
3. Turn the red Emergency Stop button clockwise to the on position at both
the ground and platform controls.
4. At the Ground Controls panel, press and hold the Lift/Lower Switch to the
DOWN position, then turn on the Key Switch to the "Ground" position.
5. Hold the Lift/Lower Switch in this position until a continuous alarm
sounds, signalling that the brake has been released.
Engage Brakes Before Driving
1. Turn the Key Switch to the OFF position to reset the brake.
BE SURE THAT THE BRAKES ARE ENGAGED BEFORE REMOVING THE
WHEEL CHOCKS������
