Figure 5 Fastening the captive screws on the power module
Removing the power module
1.
Wear an ESD wrist strap, and make sure the wrist strap makes
good skin contact and is reliably grounded.
2.
Use a Phillips screwdriver to loosen the captive screws on the
power module.
3.
Hold the handle of the power module with one hand to pull it part
way out of the slot. Support the module bottom with the other to
take out the module slowly.
Connecting and removing the power cord
WARNING!
When you connect and remove the power cord, make sure the
power switch is turned off.
CAUTION:
The NSQM2AC1400 power module uses a 16A power cord.
Prepare a 16A power strip for the power module.
8
