The following describes the procedure for connecting a power cord.
To remove a power cord, follow the inverse order.
To connect the power cord:
1.
Use a Phillips screwdriver to remove the screws from the power
cord retainer and remove the right part of the retainer.
2.
Connect the power cord to the power receptacle on the power
module.
3.
Use screws to fasten the right part of the retainer to the other
part to lock the power cord.
4.
Connect the other end of the AC power cord to the AC power
source.
Figure 6 Connecting the power cord
1
2
3
9
