Event Lighting PAR4X12B User Manual page 6

Purple
Yellow
Using WDMX Mode
Transmitters
Press the button to connect all unconnected receivers in the coverage area.
Press the button for 3 seconds to disconnect all receivers in the coverage area.
Receivers
Press the button for 3 seconds to disconnect the device from the transmitter it is currently
connected to.
Note: The colour of the light will indicate the group. Refer to Table 2 below.
Note: The receiver will not connect with a new transmitter unless it is disconnected first.
Table 2 WDMX Status Indicators
Protocol
W-DMX Receive
W-DMX Transmit
Using EL/GZ Wireless DMX Mode
Changing Channel Group
Press the button to display the current channel group being used.
Press the button again to cycle through the groups. The colour of the light will indicate the group
as shown in Table3.
Table 3 Status Indicators
Protocol
ELDMX / GZ
www.event-lighting.com.au
Action
White
Red
Red Fast Flash
Green Fast Flash
Green Slow Flash
Green
Red
Blue Fast Flash
Blue Slow Flash
Blue
Action
Solid Colour (Red, Green,
Blue, Yellow, Cyan, Purple,
White*)
Flashing Red
Flashing Green
WDMX G4 Transmit
GZ Receive (Receiver Only)
Description
No connection
Deleting Connection
Connection Lost
Connecting to Transmitter
Connected but no DMX signal
Connected with DMX signal
Deleting All Receivers
Connecting with the receivers
No DMX input
Transmitting DMX
Description
1 of the 7* colour groups
(*7th white only in GZ mode, 6 in ELDMX mode)
Transmitting DMX
Receiving DMX
5
