6-3 System operation setup for Body-Pack transmitter // UF-10TB
6-3-1 Turn power on for UF-10TB Body-Pack transmitter (Fig. 5)
(1) Turn on power: press power key once
(2) Shut down power: press and hold power key for 2 seconds.
(3) Mute setup : When microphone is in use and mute setup is needed:
Set mute: short press power key once; indicator lamp flashes in red.
Cancel mute: short press power key again to cancel mute.
(4) Leave the setting window: press the power key once the LCD display will return to the
main window.
6-3-2 Menu function setup :
Press and hold SET key for 2 seconds; enter into function setup menu;
(1) Press
(2) After entering into menu, press
SET key to save setting.
1. Freq.: set frequency
(1) Press
screen.
(2) After going to frequency adjustment screen, first adjust left 3 digits ;
Press
,
SET key to adjust right 3 digits
(3) Adjust right 3 digits : press
after adjustment press SET key to save setting.
35
Professional Wideband (60~75MHz) True Diversity System
,
keys to select desired item; press SET key to enter into menu.
,
keys to Freq. ; press SET key to enter into frequency adjustment
keys with "+/-" 1 MHz as unit change; after adjustment press
,
keys to select desired value : press
,
keys with "+/-" 0.025 MHz as unit change;
Fig. 5
UHF PLL Transmitter
Freq.
Group
Sensit.
Attenuate
Frequency
G: 1
C:1
625
.500
Frequency
G: 1
C:1
625 .
500
