Drive Technology \ Drive Automation \ System Integration \ Services
®
MOVI-PLC
advanced DHF41B Controller
DeviceNet and PROFIBUS DP-V1
Fieldbus Interfaces
Manual
Edition 03/2009
16658426 / EN
