Drive Technology \ Drive Automation \ System Integration \ Services
®
MOVI-PLC
advanced Controller
Remote Maintenance via ORA11B
Manual
Edition 09/2008
16717228 / EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOVI-PLC advanced and is the answer not in the manual?

Questions and answers

Related Manuals for SEW-Eurodrive MOVI-PLC advanced

Summary of Contents for SEW-Eurodrive MOVI-PLC advanced

  • Page 1 Drive Technology \ Drive Automation \ System Integration \ Services ® MOVI-PLC advanced Controller Remote Maintenance via ORA11B Manual Edition 09/2008 16717228 / EN...
  • Page 2 SEW-EURODRIVE – Driving the world...

  • Page 3: Table Of Contents

    1 General Notes ......................4 Use of the manual ..................4 Structure of the safety notes ................4 Right to claim under warranty ................ 5 Exclusion of liability ..................5 Copyright notice ..................... 5 2 Safety Notes ......................6 Preliminary information .................. 6 General ......................

  • Page 4: General Notes

    General Notes Use of the manual General Notes Manual Use of the manual The manual is part of the product and contains important information on operation and service. The manual is written for everyone starting up or servicing this product. The manual must be accessible and legible.

  • Page 5: Right To Claim Under Warranty

    General Notes Right to claim under warranty Right to claim under warranty You must observe this manual as the prerequisite for fault-free operation and fulfillment of any right to claim under warranty. Therefore, read the documentation before you start working with the software and the connected units from SEW-EURODRIVE. Make sure that the documentation is available to persons responsible for the system and its operation as well as to persons who work independently on the unit.

  • Page 6: Safety Notes

    Safety Notes Preliminary information Safety Notes The following basic safety notes are intended to prevent injury to persons and damage to property. The operator must make sure that the basic safety notes are read and ob- served. Ensure that persons responsible for the machinery and its operation as well as persons who work independently have read through the documentation carefully and understood it.

  • Page 7: Designated Use

    Safety Notes Designated use All activity in the other areas of transportation, storage, operation, and disposal must be carried out by persons who are appropriately trained. Designated use ORA11B is an analog modem with integrated router and a 4-port switch, which allows remote access to connected units.

  • Page 8: System Description

    MOVI-PLC advanced controller and all units connected to the system bus. Engineering PC with analog modem Remote system location SBus Ethernet ® MOVI-PLC advanced Axis 3 Axis 1 Axis 2 64004AEN Manual – MOVI-PLC® advanced Controller Remote Maintenance via ORA11B...
  • Page 9 System Description Remote maintenance via the ORA11B modem Scope of delivery The scope of delivery of the ORA11B option (part number 1822 005 3) consists of: of the ORA11B • ORA11B modem option • 2 telephone cables (TAE-N to RJ12 and RJ12 to RJ12), each 3 m long Optional scope •...

  • Page 10: Assembly And Installation Notes

    Assembly and Installation Notes Step-by-step instructions for mounting ORA11B to a DIN rail Assembly and Installation Notes Step-by-step instructions for mounting ORA11B to a DIN rail Proceed as follows: HAZARD! Moisture and liquids can enter the interior of the ORA11B. Severe or fatal injuries from electric shock.

  • Page 11: Step-By-Step Instructions For Removing Ora11B From A Din Rail

    Assembly and Installation Notes Step-by-step instructions for removing ORA11B from a DIN rail Step-by-step instructions for removing ORA11B from a DIN rail Proceed as follows: HAZARD! Open electric components. Severe or fatal injuries from electric shock. • Switch off the power supply of the ORA11B and secure it against being switched back on inadvertently before removing the unit.
  • Page 12 Assembly and Installation Notes Step-by-step instructions for removing ORA11B from a DIN rail • Move and hold the screwdriver towards the ORA11B (see following figure). This draws apart the plastic spring of the movable latch hook. 64185AXX • First pull ORA11B forward and then upward and away from the DIN rail (see follow- ing figure).

  • Page 13: Connections And Terminals At The Front Of Ora11B

    Assembly and Installation Notes Connections and terminals at the front of ORA11B Connections and terminals at the front of ORA11B The following figure shows the connections and control elements of the ORA11B option necessary for remote maintenance. ORA11B Reset Power Data Status 64063AXX...

  • Page 14: Connecting Ora11B To An Analog Telephone Line

    Assembly and Installation Notes Connections and terminals at the front of ORA11B 4.3.2 Connecting ORA11B to an analog telephone line To connect the modem to the analog telephone line, use the supplied connection cable TAE-N to RJ12 (alternative: RJ12 to RJ12). Insert the RJ12 plug connector [2] in the RJ45 socket of the ORA11B and the TAE-N plug connector [1] in the telephone jack (see following figure).
  • Page 15 Assembly and Installation Notes Connections and terminals at the front of ORA11B The following table shows the pin assignment of the RJ12 and TAE-N plug connectors. 1 2 3 4 5 6 RJ12 TAE-N 64178AXX RJ45 TAE-N Description Not connected For connecting a downline telephone Incoming telephone line (outside line or extension line) For connecting a downline telephone...

  • Page 16: Connecting Movi-Plc ® Advanced To Ora11B

    Assembly and Installation Notes Connections and terminals at the front of ORA11B ® 4.3.3 Connecting MOVI-PLC advanced to ORA11B ® Use an Ethernet cable (RJ45 to RJ45) to connect X37 of the MOVI-PLC advanced con- troller with an Ethernet switch (LAN 1 - LAN 4) of the ORA11B option (see following figure).

  • Page 17: Connections And Terminals At The Bottom Of Ora11B

    Assembly and Installation Notes Connections and terminals at the bottom of ORA11B Connections and terminals at the bottom of ORA11B 4.4.1 Voltage supply of ORA11B 10...60 VDC 64177AXX Terminal Designation Description 10 ..60 VDC Voltage supply Mass Manual – MOVI-PLC® advanced Controller Remote Maintenance via ORA11B...

  • Page 18: Configuration

    Configuration Used components (topology) Configuration Used components (topology) ® Engineering PC ORA11B MOVI-PLC advanced Ethernet cable for configuration purposes Ethernet cable Data transmission analog telephone line 64005AEN Overview of assigned IP addresses NOTE Other IP addresses not listed as examples can be used as well. Note that all IP addresses must be in the network defined by the net mask.

  • Page 19: Configuration Of Ora11B

    Configuration Configuration of ORA11B Configuration of ORA11B 5.3.1 Default settings The ORA11B modem has been configured with the following default settings: Menu [Basic Settings] / [Web Interface] / [Authentication] User name Password ORA11B Menu [Basic Settings] / [IP Addresses (LAN)] IP address 192.168.10.3 Net mask...

  • Page 20: Establishing A Network Connection To The Ora11B Modem

    Configuration Configuration of ORA11B 5.3.2 Establishing a network connection to the ORA11B modem ORA11B is configured via a network connection between ORA11B and a PC. NOTE We recommend to use a second network card in the PC. This avoids interrupting an existing network connection and re-configuring it.
  • Page 21 Configuration Configuration of ORA11B 3. Select "Internet Options" from [Start] / [System Configuration]. The "Internet Proper- ties" window is displayed (see following figure). Select the "Connections" tab [1] and click on [LAN Settings] [2] in the "Local Area Network (LAN) Settings" field. 63987AEN The "Local Area Network (LAN) Settings"...

  • Page 22: Changing Default Settings

    Configuration Configuration of ORA11B 5.3.3 Changing default settings Once ORA11B has been connected to the PC via a patch or crossover cable, you can enter the default IP address 192.168.10.3 in the browser. You have to enter your user name and password to avoid unauthorized access (see fol- lowing figure).
  • Page 23 Configuration Configuration of ORA11B After logging in successfully, the start page of ORA11B opens (see following figure). You can enter the default settings (see chapter 5.3.1) under the respective menu item. For more information, refer to the online help under "Display help text" 12023AEN NOTE Do not use the browser button [Update] to update the content of the page.

  • Page 24: Establishing A Remote Maintenance Connection Via Ora11B

    Configuration Establishing a remote maintenance connection via ORA11B Establishing a remote maintenance connection via ORA11B Proceed as follows: 1. First, call up the network connection wizard (see following figure). To do so, select [Start] / [Settings] / [Network and Dial-up Connections] / [Make New Connection]. 12031AEN The network wizard is called.
  • Page 25 Configuration Establishing a remote maintenance connection via ORA11B 4. Enter the call number of the network to which you want to establish a connection (see following figure). To dial out of a private phone system, an outside line must first be selected by entering a 0.
  • Page 26 Configuration Establishing a remote maintenance connection via ORA11B 7. To complete the network connection wizard, enter a name for the modem connection (e.g. remote maintenance) and tick the "Add a shortcut to my desktop" checkbox (siehe following figure). 12037AEN Click on the [Finish] button. The "Connect Remote Maintenance" window opens. 8.
  • Page 27 Configuration Establishing a remote maintenance connection via ORA11B 9. Select the "General" tab. In the "Connect using:" selection field, tick the "Modem ..." checkbox. Click the [Configure...] button [1]. The "Modem Configuration" window is displayed (see following figure). 63997AEN If necessary, deactivate the "Enable modem compression" [2] checkbox in the "Hard- ware features"...
  • Page 28 Configuration Establishing a remote maintenance connection via ORA11B 10.Select the "Networking" tab. In the "Components checked ...:" selection field, deacti- vate the checkboxes "File and printer sharing for Microsoft networks" [2] and "Client for Microsoft network" [3] (see following figure on the left). Activate the "Internet protocol (TCP/IP)"...
  • Page 29 Configuration Establishing a remote maintenance connection via ORA11B 11.In the last step, select the menu items [Start] / [Settings] / [System configuration] / [System] / [Hardware] / [Device manager] / [Modems]. Select the used modem Make a right mouse click to open the context menu and choose "Properties" (see following figure).

  • Page 30: Testing The Modem Connection

    Configuration Testing the modem connection Testing the modem connection Click the [Dial] button to close test the modem connection. 12038AEN The connection is established (see following figure). 12039AEN To display the status of the modem connection, highlight the shortcut on the desktop, right-click on it and select "Status"...
  • Page 31 Configuration Testing the modem connection The status of the modem connection is displayed (see following figure). 12041AEN Now, ORA11B responds to a "ping" command (see following figure). 12042AEN ® MOVI-PLC advanced also responds to a "ping" command (see following figure). 12043AEN Manual –...

  • Page 32: Establishing A Connection On The Engineering Pc

    Configuration Establishing a connection on the engineering PC ® The file "NetConfig.cfg" of MOVI-PLC advanced must contain the following entries under Ethernet 2: <Ethernet2> <IPAddress>192.168.10.4</IPAddress> <Netmask>255.255.255.0</Netmask> </Ethernet2> Establishing a connection on the engineering PC ® Select the entry "Ethernet" [1] in MOVITOOLS MotionStudio under Network communi- cation connections.
  • Page 33 Configuration Establishing a connection on the engineering PC Select the "SMLP settings" "1" tab. In the "Basic settings" group box, in the input field ® "Broadcast IP Address" [2], enter the IP address of MOVI-PLC advanced (see follow- ing figure). 64003AEN ®...

  • Page 34: Technical Data

    Technical Data General technical data Technical Data General technical data General technical data of ORA11B Operating voltage DC 10 - 60 V Power consumption in standby mode Power consumption when connection is active High level: 4 - 12 V Input level Low level: 0 - 1 V Current consumption of an active input against Typically 0.35 mA...

  • Page 35: Index
