Design and function
R 40
5.7.2

Remote control

Using protective dust caps!
Protective dust caps protect the connection sockets and therefore the machine against
dirt and damage.
• The protective dust cap must be fitted if there is no accessory component being operated
on that connection.
• The cap must be replaced if faulty or if lost!
The remote controls are operated via the 19-pole remote control connection socket
(analogue) or the 7-pole remote control connection socket (digital), depending on the
model.
5.8 R 40
• Setting the operating point via the wire speed (single-dial operation)
• Arc length correction
• Change over, display, create or change up to 16 welding programs.
• Switch superpulse function on or off.
• Change over between standard MIG welding and pulse arc MIG welding
(if supported by the welding machine).
24
CAUTION
NOTE
099-008717-EW501
24.03.2011
