6.
taking Care oF Meridian
6.1 Technical information
operating altitude:
with decompression – sea level to approximately 4000m/13300ft
without decompression (GAUGE mode) – at any altitude
Max operating depth:
120m/394ft; resolution is 0.1m until 99.9m and 1m at depth deeper than 100m. Resolution
in ft is always 1ft. Accuracy is within 2% ±0.2m/1ft.
decompression calculation range:
0.8m to 120m / 3ft to 394ft
Clock:
quartz clock, time, date, dive time display up to 999 minutes
oxygen concentration:
adjustable between 21% and 100%
operating temperature:
-10 ºC to +50 ºC / 14F to 122F
power supply:
CR2032 litium battery
Life of the battery:
2 years or 300 dives, which ever comes first. Actual battery life depends on the number of
dives per year, the length of each dive, the water temperature and the usage of backlight.
6.2 Maintenance
The depth accuracy should be verified every two years, by an authorized SCUBAPRO
dealer. Aside from that, Meridian is virtually maintenance free. Meridian is manufactured
from highest grades of stainless steel. Salt water and substances dissolved in it may
cause corrosion, surface rust or build an organic film which may disturb the functions of
the Meridian. Therefore, it is necessary to rinse it carefully with fresh water after each dive
and change the battery when needed. To avoid possible problems with your Meridian, the
following recommendations will help assure years of trouble free service:
• avoid dropping or jarring your Meridian
• do not expose Meridian to intense, direct sunlight
• do not store Meridian in a sealed container, always ensure free ventilation
• If there are problems with the water contact, use soapy water to clean Meridian and dry
it thoroughly. Do not use silicone grease on the water contacts!
• Do not clean Meridian with liquids containing solvents.
• Check the battery capacity before each dive.
• If the battery warning appears, replace the battery.
• If any error message appears on the display, take Meridian back to an authorized
SCUBAPRO dealer.
SCUBAPRO MERIDIAN
6. taking care of Meridian
53
