S
G
ERVICE
UIDE
12. Remove the LIBER holder.
13. Separate the LED light guide panel and LIBER holder.
14. Remove the self-tapping screws M2-5mm (521-013000-5R0 x4) and remove the FFC cable.
Z-8072 Service Guide
9 / 11
