Scanner Parts - Zebex Z-8072 Service Manual

Scanner Parts

The scanner includes the following parts:
NO. P/N
1 521-202000-4R0
2 521-013000-5R0
3 521-003000-8R0
4 521-004000-8R0
5 521-604000-010
6 684-100400-028
7 866-807203-005
8 866-807200-401
9 030-005524-430
10 522-904000-5R3
11 866-807201-306
12 564-080720-002
Z-8072 Service Guide
Name
Self tapping screw M1.6-4mm
Self tapping screw M2-5mm
Self tapping screw M2-8mm
Self tapping screw M3-8mm
Self tapping screw M3-10mm
Z-8072 dust cover
Z-8072 center mirror base assmbly
Z-8072 engine assembly
Sensor Board FPC (EMI) 24 Pin
Z-8072 adjustable fixing screw
Z-8072 stand base assembly
Z-8072 dust cover holder
S G
ERVICE UIDE
Quantity
2
14
4
4
4
1
1
1
1
2
1
1
3 / 11
