Troubleshooting Guide
Sensor circuits
NO: Problem appears to be related to the signal loop connected to the IMx input.
YES: Problem appears to be related to the IMx (hardware, installation or
Checking digital channels
Be aware that digital inputs 1 to 4 are configurable for different types of sensors, via DIP
switch settings, whilst digital inputs 5 to 8 have fixed characteristics and provide no
sensor power. Refer to
Effective troubleshooting for tacho signals will likely require a handheld/portable
oscilloscope or DMM with oscilloscope capabilities, a battery powered unit being
preferred. It will be hindered if the IMx-S cannot be accessed when the speed signal is
active.
1. Where applicable, check the sensor installation, the security of the mounting, the
gap to the target and the differential gap between target and no target, conditions.
Ensure these are acceptable for the sensor being used and that the sensor output
will cross the trigger threshold for the particular IMx-S digital channel being used.
2. Identify the digital input terminals where the channel in question is connected to
the IMx-S. Confirm that the wiring is correct for the sensor type in use and where
applicable, the DIP switch settings are correct.
3. Is sensor power, supposed to be, supplied by the IMx-S?
NO: Skip to step 4, dynamic, oscilloscope checks
YES: The sensor must use a digital channel in the range 1 to 4. Measure the DC
a. Is the measured voltage approximately 24 V DC, as expected?
YES: Skip to step 4, dynamic, oscilloscope checks
NO: Disconnect the sensor cable from the A (power) terminal and recheck the
b. Is the measured voltage now around 24 V DC as expected?
YES: Double check that the sensor is compatible, especially that the sensor current
To confirm a sensor/cable fault: if available try substituting an alternative sensor or
confirm that in a known working installation the same type of sensor does not
load the IM se so po e i this a .
NO: The test suggests a fault in the IMx-S, contact TSG for further advice.
4. When a speed signal is expected to be present, observe the signal at the B (signal)
and 0 (common) terminals on an oscilloscope. Is the expected pulsed waveform
present?
NO: Cable, sensor or installation issue. If practicable replace the sensor by a signal
5 - 6
Continue with further checks on the source equipment and the integrity of the
interconnecting cables.
configuration) or to a compatibility issue with the sensor. If on rechecking the
aspects advised above, no reason for the measurement error is found, contact
TSG for advice.
Digital Inputs, for further detail.
voltage between the A (power) and 0 (common) terminals using a digital
voltmeter.
voltage across the A and 0 terminals.
requirement is within the capability of the IMx-S.
source to test the measurement chain, excluding sensor/target, and to verify
