Technical Data

Analogue Inputs

Analogue Inputs
•
Analogue differential inputs:
–
–
•
Individual 24 V power supply, maximum 35 mA per channel
•
Selectable standard accelerometer power supply (4 mA constant current)
•
Input range: ±25 V
•
Impedance: >100 kΩ

Digital Inputs

•
Digital opto-isolated inputs:
–
–
•
Individual 24 V power supply, maximum 30 mA per channel:
–
–
•
Trigger level: 2,9 V
–

Outputs

•
Relay driver outputs:
–
–
•
System relay outputs:
–
–

Analogue Measurement

•
24-bit AD conversion enabling continuous transient capture (no gain or AC/DC
switching necessary)
•
True simultaneous sampling, with no multiplexing:
–
–
6 - 2
IMx-S 16: 16
IMx-S 32: 32
IMx-S 16: 8
IMx-S 32: 16
IMx-S 16: 4 channels
IMx-S 32: 8 channels
For inputs used with a signal level of 12 to 24 V note that the pulse should be
≥ 12 V.
IMx-S 16: 4
IMx-S 32: 8
IMx-S 16: 1
IMx-S 32: 2
IMx-S 16: all 16 channels
IMx-S 32: all 32 channels
