Chapter 6: Utilities

Display

The LCD OPTIONS utility enables you to adjust the contrast of the text on the display and the backlight
time.
Contrast Level
The contrast level is 0 (lightest) to 10 (darkest). To change it:
1. Press the UP or DOWN ARROW to highlight the option.
2. Press the ADJUST soft key to display the option's numerical scroll box.
3. Press the UP/DOWN ARROW keys or the corresponding numerical key to select your
preference.
4. Press the SAVE soft key to save your setting or the BACK soft key to return to the
CONTRAST LEVEL screen without saving the changes.
Backlight Time
Backlight time is from 0 to 60 seconds. To change it:
1. Press the UP or DOWN ARROW to highlight the option.
2. Press the ADJUST soft key to display the option's numerical scroll box.
3. Press the UP/DOWN ARROW keys or the corresponding numerical key to select your
preference.
4. Press the SAVE soft key to save your setting or the BACK soft key to return to the
BACKLIGHT screen without saving the changes.
CONTRAST LEVEL
BACKLIGHT TIME
10
CONTRAST LEVEL
BACKLIGHT TIME
60
25
• •
10
60
(1-10)
10
60
SEC
Current settings
Current settings
