Page 1: Sdc-Cf10G
CF10G HARDWARE INTEGRATION GUIDE VERSION 2.2 Americas: +1-800-492-2320 Option 3 Europe: +44-1628-858-940 Hong Kong: +852-2923-0610 www.lairdtech.com/wireless... -
Page 2: Revision History
Updated Pin table. 1.02 9/08/2010 Update I/O information. 1.03 5/18/2011 Updated Supported Operating Systems in Specs table. 11/07/2012 Updated formatting (Laird). 12/19/12 Removed EN 301.893 standard. 10/23/13 Removed references to summitdata.com Embedded Wireless Solutions Support Center: Americas: +1-800-492-2320 http://ews-support.lairdtech.com Europe: +44-1628-858-940 www.lairdtech.com/wireless... -
Page 3: Table Of Contents
SDC-CF10G Hardware Integration Guide ONTENTS SDC-CF10G ..............................1 Revision History ............................2 Contents ............................... 3 Scope ................................4 Operational Description ..........................4 Block Diagram .............................. 5 Specifications ............................... 5 Recommended Operating Conditions ....................10 Pin Definitions ............................10 Mechanical Specifications ......................... 12 Connector Overview .......................... -
Page 4: Scope
The frequency stability for both 2.4 GHz (802.11b and 802.11g) operation is +/- 20 ppm. The CF10G has its own RF shielding and does not require shielding provided by the host device into which it is installed in order to maintain compliance with applicable regulatory standards. As such, the device may be tested in a standalone configuration via an extender card. -
Page 5: Block Diagram
SDC-CF10G Hardware Integration Guide LOCK IAGRAM PECIFICATIONS Description Feature 16-bit Compact Flash Type I with 50-pin connector System Interface Note: This card is not designed for operation in the CF slot on standard laptop and desktop PCs. For these devices,... - Page 6 SDC-CF10G Hardware Integration Guide Description Feature 3.3 mm (0.13 in.) Thickness 15 g (0.5 oz.) Weight 50-pin connector Mounting Through hole (non-metallic screw recommended) Direct Sequence-Spread Spectrum (DSSS) Wireless Media Orthogonal Frequency Divisional Multiplexing (OFDM) Carrier sense multiple access with collision avoidance...
- Page 7 SDC-CF10G Hardware Integration Guide Description Feature 1 Mbps: -96 dBm Typical Receiver Sensitivity 2 Mbps: -95 dBm 5.5 Mbps: -94 dBm 6 Mbps: -94 dBm 9 Mbps: -91 dBm 11 Mbps: -90 dBm 12 Mbps: -88 dBm 18 Mbps: -86 dBm...
- Page 8 LEAP ETSI Regulatory Domain Compliance EN 300 328 V1.7.1 Note: For additional information, refer to the EN 301 489-1 V1.9.2 Certifications section of the CF10G page: EN 301 489-17 V2.2.1 http://www.lairdtech.com/products/cf10g EN 50371 EN 60950-1 EN 62311:2008 *EN 300 328...
- Page 9 SDC-CF10G Hardware Integration Guide Description Feature Wi-Fi Alliance Certifications 802.11a, 802.11b, 802.11g WPA Enterprise WPA2 Enterprise Cisco Compatible Extensions (Version 4) Limited Lifetime Warranty All specifications are subject to change without notice Embedded Wireless Solutions Support Center: Americas: +1-800-492-2320 http://ews-support.lairdtech.com Europe: +44-1628-858-940 www.lairdtech.com/wireless...
-
Page 10: Recommended Operating Conditions
SDC-CF10G Hardware Integration Guide Recommended Operating Conditions Min. Typical Max. Units Comments Parameter Supply Voltage VDDIO, VDDBUS 1.71 1.89 VDDCORE, PLLVDD, AVDD Logic Inputs – – , Input High Voltage – – , Input Low Voltage Logic Outputs – –... - Page 11 SDC-CF10G Hardware Integration Guide Power Description Number Name Type No Connect Slot0_data11 Data bus, bit 11 Slot0_data12 Data bus, bit 12 Slot0_data13 Data bus, bit 13 Rfu_data14 Data bus, bit 14 Slot0_data15 Data bus, bit 15 Slot0_nCE1 Enable for even-numbered address bytes. Active low.
-
Page 12: Mechanical Specifications
SDC-CF10G Hardware Integration Guide ECHANICAL PECIFICATIONS Connector Overview CF10G connector: 50-pin connector RF L AYOUT ESIGN UIDELINES The following is a list of RF layout design guidelines and recommendation when installing a Summit radio into your device. Do not run antenna cables directly above or directly below the radio. -
Page 13: Regulatory
Hardware Integration Guide EGULATORY Certified Antennas The SDC-CF10G has been tested to the regulatory standards defined in the “Certifications” section of the Specifications table above. It incorporates an integrated dual band antenna that supports transmit and receive diversity: Type: Dipole Maximum 2.4 GHz Gain: 0 dBi... -
Page 14: Industry Canada
Industry Canada User’s Guide Requirements As outlined in the Operational Description, the SDC-CF10G complies with Industry Canada (IC) rules for a Limited Modular Approval. To leverage Summit’s grant, the two conditions below must be met for the host device into which the SDC-CF10G is integrated: 1. -
Page 15: European Union
RF module in the user’s manual of the device into which the SDC-CF10G is integrated. . In addition to the required FCC statements outlined above, the following IC statements must be added in their entirety and without modification into a prominent place in the user’s guide for the device into which the SDC-CF10G is integrated:... - Page 16 SDC-CF10G Hardware Integration Guide EN 301 489-17 V1.2.1 (2002-08) Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment and services; Part 17: Specific conditions for 2,4 GHz wideband transmission systems and 5 GHz high performance RLAN equipment EU 2002/95/EC (RoHS) ...
- Page 17 SDC-CF10G Hardware Integration Guide citiem ar to saistītajiem noteikumiem. [manufacturer name] [equipment type] Šiuo deklaruoja, kad šis atitinka esminius Lietuvių reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas. [Lithuanian] [naam van de fabrikant] [type van toestel] Hierbij verklaart dat het toestel overeenstemming is met de essentiële eisen en de andere relevante bepalingen Nederlands van richtlijn 1999/5/EG.
