MSD45N to provide robust performance when implemented with a cellular system. The MSD45N has its own RF shielding and does not require shielding provided by the host device into which it is installed in order to maintain compliance with applicable regulatory standards. As such, the device may be tested in a standalone configuration via an extender card.
Laird MSD45N Hardware Integration Guide, version 1.1 SDIO Timing Requirements The following figure (Figure 1) and table display SDIO default mode timing. Note: The SDIO bus should not exceed a 25 MHz clock rate. Figure 2: SDIO Default Mode Timing Note: Timing is based on CL ≤...
Laird MSD45N Hardware Integration Guide, version 1.1 EFINITIONS Table 5: Pin Definitions Default Name Ref. Description If Unused State Must be Ground connected to No Connect No internal connection. Leave it open Leave open 3-Wire Wi-Fi/BT coexistence signal BT_PRIORITY Hi-Z...
Page 11
Laird MSD45N Hardware Integration Guide, version 1.1 Default Name Ref. Description If Unused State Must be Ground connected to Must be Ground connected to No Connect No internal connection. Leave it open Leave open No Connect No internal connection. Leave it open...
Page 12
5 µsec (T and T ) after the VCC3_3 reaches its high state. See Figure To reset the MSD45N, set the CHIP_PWD_L in low state longer than 5 µsec (T ). See Figure Figure 3: Power on/down timing...
Laird MSD45N Hardware Integration Guide, version 1.1 MSD40NBT and MSD45N Pin Comparison Table Pin Name Pin Name Pin Name Pin Name Pin # Pin # MSD40NBT MSD40NBT MSD45N MSD45N No Connect BT_UART_TXD No Connect BT_RST_L No Connect BT_PRIORITY BT_PRIORITY No Connect...
SDIO host interface (1.8V or 3.3V typically, but it can be anything in between these values). The SDIO host must wait a minimum of 5 µsec before initiating access to the MSD45N after VCC3_3 ramps up and settles...
Hardware Integration Guide, version 1.1 Mounting The MSD45N connects to the host via a 60-pin connector. In addition, there are three mounting holes used to secure the device to the host using 2 mm mounting screws. Laird recommends a 1.5 mm metal spacer (bushing) with a conductive mounting screw to connect the exposed ground pads of the radio circuit board to the host ground plane.
MSD45N is integrated. The following FCC statements must be added in their entirety and without modification into a prominent place in the user’s guide for the device into which the MSD45N is integrated: Embedded Wireless Solutions Support Center: Laird Technologies http://ews-support.lairdtech.com...
Page 18
Laird MSD45N Hardware Integration Guide, version 1.1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Integration Guide. Industry Canada Note: You must place “Contains IC ID: 3147A-MSD45N” on the host product in such a location that it can be seen by an operator at the time of purchase. User’s Guide Requirements (for Model # MSD45N)
Page 20
Laird MSD45N Hardware Integration Guide, version 1.1 Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
European Union User’s Guide Requirements The integrator must include specific information in the user’s guide for the device into which the MSD45N is integrated. In addition to the required FCC and IC statements outlined above, the following R&TTE statements must be added in their entirety and without modification into a prominent place in the user’s guide for the device into which the MSD45N is integrated: This device complies with the essential requirements of the R&TTE Directive 1999/5/EC.
Page 22
Laird MSD45N Hardware Integration Guide, version 1.1 Česky [Jméno výrobce] [typ za ř ízení] tímto prohlašuje, že tento je ve shodě se základními [Czech] požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES. [fabrikantens navn] [udstyrets Dansk Undertegnede erklærer herved, at følgende udstyr...
Page 23
Laird MSD45N Hardware Integration Guide, version 1.1 [Slovenian] ostalimi relevantnimi določili direktive 1999/5/ES. [Menovýrobcu] [typzariadenia] Slovensky týmtovyhlasuje, že spĺňazákladnépožiadavky a [Slovak] všetkypríslušnéustanoveniaSmernice 1999/5/ES. Suomi [Valmistaja = manufacturer] vakuuttaa täten että [type of equipment = laitteen tyyppimerkintä] [Finnish] tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä...
Laird MSD45N Hardware Integration Guide, version 1.1 A: S PPENDIX CHEMATIC The following MSD45N schematic may be used as a reference. Figure 8: Laird MSD45N Schematic Embedded Wireless Solutions Support Center: Laird Technologies http://ews-support.lairdtech.com Americas: +1-800-492-2320 Option 2 Europe: +44-1628-858-940 www.lairdtech.com/wireless...
