Laird BT830 Hardware Integration Manual

Bluetooth v4.0 dual-mode uart hci module
Hide thumbs Also See for BT830:
Table of Contents

Advertisement

Quick Links

Download this manual
Bluetooth v4.0 Dual-Mode UART HCI Module
BT830 – Hardware Integration Guide (HIG)
Version 0.1 - PRELIMINARY
Americas: +1-800-492-2320 Option 2
Europe: +44-1628-858-940
Hong Kong: +852-2923-0610
www.lairdtech.com/bluetooth

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT830 and is the answer not in the manual?

Questions and answers

Related Manuals for Laird BT830

Summary of Contents for Laird BT830

  • Page 1 Bluetooth v4.0 Dual-Mode UART HCI Module BT830 – Hardware Integration Guide (HIG) Version 0.1 - PRELIMINARY Americas: +1-800-492-2320 Option 2 Europe: +44-1628-858-940 Hong Kong: +852-2923-0610 www.lairdtech.com/bluetooth...

  • Page 2: Revision History

    BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) EVISION ISTORY Revision Date Changes 26 March 2014 Initial preliminary version CONN-GUIDE-BT830 Americas: +1-800-492-2320 Option 2 (PRELIMINARY) Europe: +44-1628-858-940 Hong Kong: +852-2923-0610 www.lairdtech.com/bluetooth...

  • Page 3: Table Of Contents

    9.2 Power Sequencing ........................24 10 Antenna Performance........................... 24 11 Mechanical Dimensions and Land Pattern ..................... 26 11.1 BT830 Mechanical Drawing ......................26 12 Implementation Note..........................27 12.1 PCB Layout on Host PCB....................... 27 13 Application Note for Surface Mount Modules ..................28 13.1 Introduction ..........................

  • Page 4: Scope

    Version 0.1 (PRELIMINARY) COPE This document describes key hardware aspects of the Laird BT830 Bluetooth HCI module. This document is intended to assist device manufacturers and related parties with the integration of this module into their host devices. Data in this document are drawn from a number of sources including data sheets for the CSR8811.

  • Page 5: Block Diagram And Descriptions

    ESCRIPTIONS Figure 1: BT830 module block diagram The BT830 is based on CSR8811A08 dual mode chip. The chip is a single-chip radio with on-chip CS8811A08 LDO regulators and baseband IC for Bluetooth 2.4 GHz systems including EDR to 3 Mbps.

  • Page 6: Specifications

    File Transfer ~TBD mA (Master; ACL link; Transmit) Internal Multilayer ceramic antenna with up to 41% efficiency. Antenna Option Physical Dimensions 8.5 x 13 x 1.6 mm (BT830 - Module) Operating -30C to +85C Environmental Storage -40C to +85C Lead Free...

  • Page 7: Pin Definitions

    Ground Ground Ground Ground Ground Ground RF signal out (50 ohm) for BT830-ST version only. Not connection for BT830-SA. Ground PCM synchronous data sync SPI chip PCM_SYNC/ Bidirectional, tri-state, select, active low Programmable SPI_CS#/...
  • Page 8 BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) Pin Name Supply Domain Description PCM synchronous data clock Bidirectional, tri-state, PCM_CLK/ SPI_CLK/ SPI clock with weak internal VDD_PADS PIO24 Programmable input/output line pull-down *See Note PCM synchronous data input Input, tri-state, with...

  • Page 9: Dc Electrical Characteristic

    BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) 6 DC E LECTRICAL HARACTERISTIC Table 3: Absolute maximum ratings Rating Unit Storage temperature ⁰C VREG_IN_HV VREG_OUT_HV VDD_PADS -0.4 Other terminal voltages VSS - 0.4V VDD + 0.4 V Table 4: Recommended operating conditions...

  • Page 10: Rf Characteristics

    BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) Normal Operation Unit Output Voltage VOL output logic level low, IOL = 4.0 mA VOH output logic level high, 0.75 x IOL = 4.0 mA Input and Tristate Currents Strong pull-up -150 µA Strong pull-down µA...

  • Page 11: Interface

    Channel skipping AFH  Priority signaling  Channel signaling  Host passing of channel instructions  The BT830 supports the WLAN coexistence schemes: Unity-3  Unity-3e  Unity+  BT830 WLAN Coexistence Schemes and LED Indication For more information see...

  • Page 12: Uart Interface

    CSR8811 UART interface provides a simple mechanism for communicating with other serial devices using the RS-232 protocol. The above figure shows the 4 signals that implement the UART function. When BT830 is connected to another digital device, UART_RX and UART_TX transfer data between the 2 devices. The remaining 2 signals, UART_CTS and UART_RTS, implement RS232 hardware flow control where both are active low indicators.
  • Page 13 Long Frame Sync is the name given to a clocking format that controls the transfer of PCM data words or samples. In Long Frame Sync, the rising edge of PCM_SYNC indicates the start of the PCM word. When the BT830 is configured as PCM master, generating PCM_SYNC and PCM_CLK, then PCM_SYNC is eight bits long.
  • Page 14 Figure 5: Short Frame Sync (Shown with 16-bit Sample) As with Long Frame Sync, BT830 samples PCM_IN on the falling edge of PCM_CLK and transmits PCM_OUT on the rising edge. PCM_OUT is configurable as high impedance on the falling edge of PCM_CLK in the LSB position or on the rising edge.

  • Page 15: Gci Interface

    BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) 8.5 GCI Interface BT830 is compatible with the GCI, a standard synchronous 2B+D ISDN timing interface. The two 64 kbps B channels are accessed when this mode is configured. Figure 7: Multi-slot Operation The start of frame is indicated by the rising edge of PCM_SYNC and runs at 8 kHz.

  • Page 16: Pcm Timing Information

    BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) Figure 8: 16-bit Slot Length and Sample Formats 8.7 PCM Timing Information Table 10: PCM Timing information Parameter Unit Symbol 4MHz DDS generation. Frequency selection is programmable. PCM_CLK frequency mclk 48MHz DDS generation. Frequency selection is programmable.
  • Page 17 BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) Symbol Parameter Unit PCM_SYNC low (long frame sync only) (a) Assumes normal system clock operation. Figures vary during low-power modes, when system clock speeds are reduced. Table 11: PCM Master Mode Timing Parameters...

  • Page 18: Pcm Slave Timing

    BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) Figure 10: PCM Master Timing Short Frame Sync 8.8 PCM Slave Timing Symbol Parameter Unit PCM clock frequency (Slave mode: input) 2048 sclk PCM clock frequency (GCI mode) 4096 sclk PCM_CLK low time...
  • Page 19 BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) Figure 11: PCM Slave Timing Long Frame Sync Figure 12: PCM Slave Timing Short Frame Sync CONN-GUIDE-BT830 Americas: +1-800-492-2320 Option 2 (PRELIMINARY) Europe: +44-1628-858-940 Hong Kong: +852-2923-0610 www.lairdtech.com/bluetooth...

  • Page 20: Pcm_Clk And Pcm_Sync Generation

    BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) 8.10 PCM_CLK and PCM_SYNC Generation BT830 has two methods of generating PCM_CLK and PCM_SYNC in master mode: Generating these signals by DDS from BT830internal 4MHz clock. Using this mode limits PCM_CLK to 128, 256 ...
  • Page 21 BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) Configure the digital audio interface using PSKEY_DIGITAL_AUDIO_CONFIG, see BlueCore Audio API Specification and the PS Key file. Figure 13: PCM Configuration The internal representation of audio samples within BT830is 16-bit and data on SD_OUT is limited to 16-bit per channel.
  • Page 22 BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) Table 14: I²S Slave Mode Timing Symbol Parameter Unit WS valid to SCK high set-up time SCK high to WS invalid hold time SCK low to SD_OUT valid delay time SD_IN valid to SCK high set-up time...

  • Page 23: Power Supply And Regulation

    UPPLY AND EGULATION See the Example Application Schematic (Error! Reference source not found.) for the regulator configuration. BT830 can be powered by either two sources listed below Method #1: Apply 3.3 V on pin-9,High-voltage linear regulator input (VREG_IN_HV), to generate the main 1.8 ...

  • Page 24: Power Sequencing

    BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) 9.2 Power Sequencing CSR recommends that all power supplies are powered at the same time. The order of powering the supplies relative to the I/O supply, VDD_PADS to VREG_IN_HV or VREG_OUT_HV, is not important.
  • Page 25 BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) Peak Avg. XY-plane -3.5 -4.2 Figure 17: XY plane Peak Avg. XZ-plane -5.3 Figure 18: XZ-plane Peak Avg. YZ-plane -4.7 Figure 19: YZ-plane CONN-GUIDE-BT830 Americas: +1-800-492-2320 Option 2 (PRELIMINARY) Europe: +44-1628-858-940 Hong Kong: +852-2923-0610...

  • Page 26: Mechanical Dimensions And Land Pattern

    BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) 11 M ECHANICAL IMENSIONS AND ATTERN 11.1 BT830 Mechanical Drawing Note: Dimensions are in mm. Tolerances: .xx ±0.03 mm .x ±1.3 mm CONN-GUIDE-BT830 Americas: +1-800-492-2320 Option 2 (PRELIMINARY) Europe: +44-1628-858-940 Hong Kong: +852-2923-0610...

  • Page 27: Implementation Note

    Keep all mounting hardware and metal clear of the area to allow proper antenna radiation. For best antenna performance, place the BT830 module on the edge of the host PCB, preferably in the corner with the antenna facing the corner.

  • Page 28: Application Note For Surface Mount Modules

    Power the on Pin-9 (VREG_IN_HV) with 3.3 V and pull-high on Pin-8 (VREG_EN_RST#) to turn on the internal regulator. The BT830 module generates 1.8 V output on Pin-10 (VREG_OUT_HV) which can supply to the other DC pin of the board.

  • Page 29: Reflow Parameters

    Version 0.1 (PRELIMINARY) 13.3 Reflow Parameters Laird surface mount modules are designed to be easily manufactured, including reflow soldering to a PCB. Ultimately it is the responsibility of the customer to choose the appropriate solder paste and to ensure oven temperatures during reflow meet the requirements of the solder paste.

  • Page 30: Fcc And Ic Regulatory

    Model US/FCC CANADA/IC BT830 BT830 DVK-BT830 The BT830 family has been designed to operate with the antenna listed below having a maximum gain of 0.5 dBi. The required antenna impedance is 50 ohms. Item Part Number Mfg. Type Gain (dBi)
  • Page 31 BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) IMPORTANT NOTE: To comply with FCC requirements, the BT830 must not be co-located or operating in conjunction with any other antenna or transmitter. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 32: European Union Regulatory

    NION EGULATORY The BT830 has been tested for compliance with relevant standards for the EU market. BT830 module was tested with a 0.5 dBi chip antenna. The OEM should consult with a qualified test house before entering their device into an EU member country to make sure all regulatory requirements have been met for their complete device.

  • Page 33: Eu Declarations Of Conformity

    Declaration: We, Laird, declare under our sole responsibility that the essential radio test suites have been carried out and that the above product to which this declaration relates is in conformity with all the applicable essential requirements of Article 3 of the EU Directive 1999/5/EC, when used for its intended purpose.

  • Page 34: Bluetooth Sig Approvals

    BT830 Hardware Integration Guide Version 0.1 (PRELIMINARY) 17 B SIG A LUETOOTH PPROVALS 17.1 Application Note: Subsystem Combinations This application note covers the procedure for generating a new Declaration ID for a Subsystem combination on the Bluetooth SIG website. In the instance of subsystems, a member can combine two or more subsystems to create a complete Bluetooth End Product solution.

  • Page 35: Additional Assistance

    Your new Design will be listed on the SIG website and you can print your Certificate and DoC. For further information please refer to the following training material: https://www.bluetooth.org/en-us/test-qualification/qualification-overview/listing-process-updates 17.2 Additional Assistance Please contact your local sales representative or our support team for further assistance: Laird Technologies Connectivity Products Business Unit Support Centre: http://ews-support.lairdtech.com Email: wireless.support@lairdtech.com...
  • Page 36 All brands and product names in this publication are registered trademarks or trademarks of their respective holders. This material is preliminary Information furnished by Laird Technologies in this specification is believed to be accurate. Devices sold by Laird Technologies are covered by the warranty and patent indemnification provisions appearing in its Terms of Sale only. Laird Technologies makes no warranty, express, statutory, and implied or by description, regarding the information set forth herein.
  • Page 37 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 38 This device is intended only for OEM integrators under the following conditions: 1) The transmitter module may not be co-located with any other transmitter or antenna, As long as 1 condition above is met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed IMPORTANT NOTE...
  • Page 39 Industry Canada statement: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 40 The final end product must be labeled in a visible area with the following: “Contains IC: 3147A-BT830”. Plaque signalétique du produit final Le produit final doit être étiqueté dans un endroit visible avec l'inscription suivante: "Contient des IC: 3147A-BT830". 2006/8/16 v1.0...
  • Page 41 Manual Information to the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual.
  • Page 42 Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device. Le présent émetteur radio (IC:3147A-BT830) a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne.
