Appendix A
A.1 Rear Panel MOTOR Connectors
The 'MOTOR DRIVE' connector is a female, 15-pin D-Type and provides drive
connection to the motors. The pin functions are detailed in Fig. A.1..
Pin
1
2
3
4
5
6
7
8
Notes
Quadrature X+/-: Differential quadrature pulses of the encoder
Encoder Index I -/+: The differential Index pulse used for homing
Limit -/+: Positive and negative limit switch signals
Stage ID: Unique Thorlabs communication interface signal used to identify the stage
connected.
Rear Panel Connector Pinout Details
8
7
6
15
14
Description
Quadrature A-
Quadrature A+
Quadrature B+
Quadrature B-
Encoder Index I-
Encoder Index I+
Negative Limit
Positive Limit
Fig. A.1
MOTOR DRIVE
5
4
3
2
1
13
12
11
10
9
Pin
9
10
Motor Phase C
11
Motor Phase A
12
Motor Phase B
13
14
15
connector pin identification
Description
GND
+5 V
GND
Stage ID
61
